WINDSHIELD AND INSTRUMENTS ASSEMBLIES для Arctic Cat M 8000 SNO PRO 153 (ORANGE) [S2015M8HSPUSO] - 2015 года выпуска
-
№АртикулНазвание
-
14718-447 POD W/DECALS - ORANGE (INC. 2-3)POD W/DECALS - ORANGE (INC. 2-3)
-
25706-234 ...POD, INSTRUMENT - ORANGE...POD, INSTRUMENT - ORANGE
-
31621-398 ...DECAL, POD - RIGHT...DECAL, POD - RIGHT
-
31621-399 ...DECAL, POD - LEFT...DECAL, POD - LEFT
-
40641-897 OUTLET, ACCESSORY - 12VOUTLET, ACCESSORY - 12V
-
50608-688 SCREEN, AIR INTAKE - RIGHTSCREEN, AIR INTAKE - RIGHT
-
50608-689 SCREEN, AIR INTAKE - LEFTSCREEN, AIR INTAKE - LEFT
-
61623-129 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
-
76606-576 VENT, INTAKEVENT, INTAKE
-
80608-736 SCREEN, INTAKE - INJECTION MOLD - RIGHTSCREEN, INTAKE - INJECTION MOLD - RIGHT
-
80608-737 SCREEN, INTAKE - INJECTION MOLD - LEFTSCREEN, INTAKE - INJECTION MOLD - LEFT
-
90609-910 SWITCH, IGNITION (INC. 10-12)SWITCH, IGNITION (INC. 10-12)
-
100430-050 ...NUT, FLANGE - IGNITION SWITCH...NUT, FLANGE - IGNITION SWITCH
-
110430-042 ...KEY, IGNITION - (Y SERIES - LEFT-SIDE CUT)...KEY, IGNITION - (Y SERIES - LEFT-SIDE CUT)
-
110430-043 ...KEY, IGNITION - (Z SERIES - RIGHT-SIDE CUT)...KEY, IGNITION - (Z SERIES - RIGHT-SIDE CUT)
-
120430-054 ...COVER, KEY...COVER, KEY
-
130620-391 SPEEDO/TACH-PREMIUM-CALIB (XF/M)SPEEDO/TACH-PREMIUM-CALIB (XF/M)
-
145706-252 BRACKET, SPEEDOMETER GAUGE - CENTER - BLACKBRACKET, SPEEDOMETER GAUGE - CENTER - BLACK
-
150423-493 NUT W/WASHERNUT W/WASHER
-
168410-616 SCREW, CAPSCREW, CAP
-
175706-250 BRACKET, SPEEDOMETER GAUGE - RIGHT - BLACKBRACKET, SPEEDOMETER GAUGE - RIGHT - BLACK
-
175706-251 BRACKET, SPEEDOMETER GAUGE - LEFT - BLACKBRACKET, SPEEDOMETER GAUGE - LEFT - BLACK
-
188053-212 WASHER, LOCKWASHER, LOCK
-
198427-602 NUT, LOCKNUT, LOCK
-
200423-355 SCREW, SHOULDERSCREW, SHOULDER
-
211623-764 NUT, EXPANSIONNUT, EXPANSION
-
226606-482 WINDSHIELD - LOW - ORANGEWINDSHIELD - LOW - ORANGE
-
238477-516 SCREW, MACHINESCREW, MACHINE
