TUNNEL AND SNOWFLAP ASSEMBLY для Arctic Cat XF 6000 CROSS-TOUR 141 (INTERNATIONAL) (ORANGE) [S2015X6DCTOSO] - 2015 года выпуска
-
№АртикулНазвание
-
-2707-051 COMPLETE CHASSIS ASSEMBLYCOMPLETE CHASSIS ASSEMBLY
-
12707-249 TUNNEL, XF-141-S/P ASSY (INC. 2-13)TUNNEL, XF-141-S/P ASSY (INC. 2-13)
-
22707-248 ...TUNNEL, FRONT - ASSEMBLY (INC. 3-4)...TUNNEL, FRONT - ASSEMBLY (INC. 3-4)
-
31607-342 ......BRACKET, MOUNTING - SUSPENSION - RIGHT......BRACKET, MOUNTING - SUSPENSION - RIGHT
-
31607-343 ......BRACKET, MOUNTING - SUSPENSION - LEFT......BRACKET, MOUNTING - SUSPENSION - LEFT
-
48060-686 ......RIVET, BLIND-DH SS64 ZINC......RIVET, BLIND-DH SS64 ZINC
-
51623-206 ...RIVET, 3/16 HUCK-M9...RIVET, 3/16 HUCK-M9
-
68422-502 ...NUT, LOCK...NUT, LOCK
-
71707-644 ...BRACKET, MOUNTING - REAR SPAR - RIGHT...BRACKET, MOUNTING - REAR SPAR - RIGHT
-
71707-645 ...BRACKET, MOUNTING - REAR SPAR - LEFT...BRACKET, MOUNTING - REAR SPAR - LEFT
-
88476-512 ...SCREW, MACHINE...SCREW, MACHINE
-
91623-257 ...RIVET, 3/16 HUCK-M5...RIVET, 3/16 HUCK-M5
-
108060-682 ...RIVET, BLIND-DH SS62 ZINC...RIVET, BLIND-DH SS62 ZINC
-
111607-251 ...TUNNEL, REAR...TUNNEL, REAR
-
128060-484 ...RIVET, BLIND-DH SS53 ZINC...RIVET, BLIND-DH SS53 ZINC
-
131607-104 ...END CAP, TUNNEL...END CAP, TUNNEL
-
140645-709 CLIP, ROUTINGCLIP, ROUTING
-
158476-820 SCREW, MACHINESCREW, MACHINE
-
161707-454 SUPPORT, FOOTREST - RIGHT - BLACKSUPPORT, FOOTREST - RIGHT - BLACK
-
161707-455 SUPPORT, FOOTREST - LEFT - BLACKSUPPORT, FOOTREST - LEFT - BLACK
-
178427-802 NUT, LOCKNUT, LOCK
-
180744-076 KIT, TOOLKIT, TOOL
-
198468-535 SCREW, MACHINESCREW, MACHINE
-
201623-637 CLIP, U-NUTCLIP, U-NUT
-
210607-996 FOOTREST - RIGHTFOOTREST - RIGHT
-
210607-997 FOOTREST - LEFTFOOTREST - LEFT
-
228470-516 SCREW, MACHINESCREW, MACHINE
-
230608-705 BRACKET, ROUTING - OIL LINEBRACKET, ROUTING - OIL LINE
-
241607-109 PROTECTOR, CHAIN CASEPROTECTOR, CHAIN CASE
-
258061-708 RIVET, BLIND-LF SS66 BLACKRIVET, BLIND-LF SS66 BLACK
-
260607-351 PROTECTOR, BRAKE DISCPROTECTOR, BRAKE DISC
-
271607-371 SHIELD, BRAKE DISCSHIELD, BRAKE DISC
-
288408-613 SCREW, CAPSCREW, CAP
-
298470-520 SCREW, MACHINESCREW, MACHINE
-
301623-130 RIVET, 3/16 HUCK-M4RIVET, 3/16 HUCK-M4
-
311607-092 ROLL, TUNNELROLL, TUNNEL
-
320630-309 PROTECTOR, HARNESS - TAILLIGHT EXTENSIONPROTECTOR, HARNESS - TAILLIGHT EXTENSION
-
331623-241 RIVET, 3/16 HUCK-M6RIVET, 3/16 HUCK-M6
-
341607-162 GUSSET, RUNNING BOARD - RIGHTGUSSET, RUNNING BOARD - RIGHT
-
341607-163 GUSSET, RUNNING BOARD - LEFTGUSSET, RUNNING BOARD - LEFT
-
351607-040 GUSSET, TUNNEL ROLL - RIGHTGUSSET, TUNNEL ROLL - RIGHT
-
351607-041 GUSSET, TUNNEL ROLL - LEFTGUSSET, TUNNEL ROLL - LEFT
-
360630-292 PROTECTOR, HARNESS - TAILLIGHTPROTECTOR, HARNESS - TAILLIGHT
-
371621-568 DECAL, TUNNEL - RIGHTDECAL, TUNNEL - RIGHT
-
371621-569 DECAL, TUNNEL - LEFTDECAL, TUNNEL - LEFT
-
380621-991 DECAL, REFLECTOR - REDDECAL, REFLECTOR - RED
-
398470-510 SCREW, MACHINESCREW, MACHINE
-
400630-328 HOUSING, TAILLIGHTHOUSING, TAILLIGHT
-
410609-898 TAILLIGHT, REDTAILLIGHT, RED
-
426606-394 SNOWFLAPSNOWFLAP
-
435611-852 DECAL, WARNING - TOWING (FRENCH)DECAL, WARNING - TOWING (FRENCH)
-
445611-853 DECAL, WARNING - TOWING (ENGLISH)DECAL, WARNING - TOWING (ENGLISH)
-
458061-706 RIVET, BLIND-LF SS64 BLACKRIVET, BLIND-LF SS64 BLACK
-
460641-257 PUMP, SHOCKPUMP, SHOCK
-
478060-630 RIVET, BLIND-DH AA68 BLKRIVET, BLIND-DH AA68 BLK
-
486606-582 SADDLEBAGSADDLEBAG
-
491623-940 MOUNT, SADDLEBAGMOUNT, SADDLEBAG
