A-ARM AND SWAY BAR ASSEMBLY для Arctic Cat XF 7000 CROSS-TOUR 141 (INTERNATIONAL) (ORANGE) [S2015X7UCTOSO] - 2015 года выпуска
-
№АртикулНазвание
-
12703-786 A-ARM, UPPER - RIGHT - BLACKA-ARM, UPPER - RIGHT - BLACK
-
12703-787 A-ARM, UPPER - LEFT - BLACKA-ARM, UPPER - LEFT - BLACK
-
28408-845 SCREW, CAPSCREW, CAP
-
32603-841 AXLEAXLE
-
48427-802 NUT, HEX FLG-NYL LOCK M8X1.25 CL8 Z & YNUT, HEX FLG-NYL LOCK M8X1.25 CL8 Z & Y
-
58427-202 NUT, HEX FLG-NYL LOCK M12X1.25 CL8 Z & YNUT, HEX FLG-NYL LOCK M12X1.25 CL8 Z & Y
-
62603-946 BUSHING, SWAYBAR-12.7MM-INNERBUSHING, SWAYBAR-12.7MM-INNER
-
72703-793 SWAYBAR, FORMED-12.7MM-PTD BLKSWAYBAR, FORMED-12.7MM-PTD BLK
-
82603-947 BUSHING, SWAYBAR-12.7MM-OUTERBUSHING, SWAYBAR-12.7MM-OUTER
-
92603-857 BRACKET, MOUNTING - SWAY BARBRACKET, MOUNTING - SWAY BAR
-
108468-621 SCREW, MACH-TSPNH M6X1.0X20 CL8.8 W/2353SCREW, MACH-TSPNH M6X1.0X20 CL8.8 W/2353
-
118476-835 SCREW, MACH-TSTRH M8X1.25X35 Z & YSCREW, MACH-TSTRH M8X1.25X35 Z & Y
-
123603-295 LINK, SWAY BARLINK, SWAY BAR
-
133703-124 A-ARM, LOWER - RIGHT - 42" (INC. 14-15)A-ARM, LOWER - RIGHT - 42" (INC. 14-15)
-
133703-125 A-ARM, LOWER - LEFT - 42" (INC. 14-15)A-ARM, LOWER - LEFT - 42" (INC. 14-15)
-
141603-895 ...BEARING, 10DU10-FRONT SUSPENSION...BEARING, 10DU10-FRONT SUSPENSION
-
152603-911 ...BEARING, SPLIT-18 X 20 X 15...BEARING, SPLIT-18 X 20 X 15
-
161623-965 NUT, LOCKNUT, LOCK
-
172603-909 BRACE, LOWER A-ARM - FRONTBRACE, LOWER A-ARM - FRONT
-
182603-916 AXLE, INNER - LOWER A-ARM - FRONTAXLE, INNER - LOWER A-ARM - FRONT
-
191623-953 SCREW, CAP-HFH M12X1.25X76 CL 10.9 MZSCREW, CAP-HFH M12X1.25X76 CL 10.9 MZ
-
208409-075 SCREW, CAP-HFH M10X1.25X75 CL10.9 Z & YSCREW, CAP-HFH M10X1.25X75 CL10.9 Z & Y
-
212603-543 AXLE, LOWER A-ARM - REARAXLE, LOWER A-ARM - REAR
-
228427-002 NUT, LOCKNUT, LOCK
