STEERING SUPPORT ASSEMBLY для Arctic Cat XF 7000 SNO PRO 137 (GREEN) [S2015XFUSPUSG] - 2015 года выпуска
-
№АртикулНазвание
-
12707-076 SPAR, FRONT (INC. 2)SPAR, FRONT (INC. 2)
-
21623-797 ...INSERT,M5X0.8-AL SERIES ALS4-580-3.3...INSERT,M5X0.8-AL SERIES ALS4-580-3.3
-
30423-403 CLAMP,TUBE-1.125"(ARDEN COV 1909 ZI)CLAMP,TUBE-1.125"(ARDEN COV 1909 ZI)
-
48470-516 SCREW,MACH-TSPNH M5X.8X16 CL8.8 Z & YSCREW,MACH-TSPNH M5X.8X16 CL8.8 Z & Y
-
51623-982 SCREW,CAP-HFH M8X1.25X30 CL8.8-Z & Y-DPTSCREW,CAP-HFH M8X1.25X30 CL8.8-Z & Y-DPT
-
61607-094 INSERT,SPAR-MALEINSERT,SPAR-MALE
-
78422-802 NUT,HEX-THK NYL M8X1.25 CL8 Z & YNUT,HEX-THK NYL M8X1.25 CL8 Z & Y
-
88408-625 SCREW,CAP-HFH M6X1.0X25 CL8.8 Z & YSCREW,CAP-HFH M6X1.0X25 CL8.8 Z & Y
-
98053-212 WASHER,LOCK-1/4 EXT TOOTH TYP A Z & YWASHER,LOCK-1/4 EXT TOOTH TYP A Z & Y
-
108427-602 NUT,HEX FLG-NYL LOCK M6X1.0 CL8 Z & YNUT,HEX FLG-NYL LOCK M6X1.0 CL8 Z & Y
-
111707-584 SUPPORT, CHASSIS - RIGHTSUPPORT, CHASSIS - RIGHT
-
121712-851 BRACKET, MOUNTING - RESONATORBRACKET, MOUNTING - RESONATOR
-
131607-121 SUPPORT, SIDE - REAR RIGHTSUPPORT, SIDE - REAR RIGHT
-
131607-133 SUPPORT, SIDE - REAR LEFTSUPPORT, SIDE - REAR LEFT
-
148408-820 SCREW,CAP-HFH M8X1.25X20 CL8.8 Z & YSCREW,CAP-HFH M8X1.25X20 CL8.8 Z & Y
-
151623-031 SCREW,SELF TAP-TSTRH #10-12X1.00SCREW,SELF TAP-TSTRH #10-12X1.00
-
160609-937 CLIP,HARNESS-PLASTICCLIP,HARNESS-PLASTIC
-
178476-630 SCREW,MACH-TSTRH M6X1.0X30 Z & YSCREW,MACH-TSTRH M6X1.0X30 Z & Y
-
188408-825 SCREW,CAP-HFH M8X1.25X25 CL8.8 Z & YSCREW,CAP-HFH M8X1.25X25 CL8.8 Z & Y
-
198427-802 NUT,HEX FLG-NYL LOCK M8X1.25 CL8 Z & YNUT,HEX FLG-NYL LOCK M8X1.25 CL8 Z & Y
-
201707-565 SUPPORT, STEERING - (BLACK)SUPPORT, STEERING - (BLACK)
-
211707-566 SPAR, REAR - RIGHT - (BLACK)SPAR, REAR - RIGHT - (BLACK)
-
225706-625 SPAR, REAR - LEFT (INC. 23-24)SPAR, REAR - LEFT (INC. 23-24)
-
236606-663 ...BRACKET, HOLD-DOWN - SEAT-BASE...BRACKET, HOLD-DOWN - SEAT-BASE
-
248060-484 ...RIVET, BLIND-DH SS53 ZINC...RIVET, BLIND-DH SS53 ZINC
-
251607-002 INSERT,UPPER SPARINSERT,UPPER SPAR
