AIR CLEANER ASSEMBLY для Arctic Cat ZR 120 (RUSSIAN) (BLACK) [S2015ZRAAARUB] - 2015 года выпуска
-
№АртикулНазвание
-
13020-094 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
-
23020-055 COVER, AIR CLEANERCOVER, AIR CLEANER
-
33020-056 FILTER, AIR CLEANERFILTER, AIR CLEANER
-
43020-057 PLATE, RETAININGPLATE, RETAINING
-
51623-661 SCREW,PT THD-TSTRH K60-2.69X16MM RIE (BLACK)SCREW,PT THD-TSTRH K60-2.69X16MM RIE (BLACK)
-
68408-825 SCREW,CAP-HFH M8X1.25X25 CL8.8 Z & YSCREW,CAP-HFH M8X1.25X25 CL8.8 Z & Y
-
73020-054 CASE, AIR CLEANERCASE, AIR CLEANER
-
88427-802 NUT,HEX FLG-NYL LOCK M8X1.25 CL8 Z & YNUT,HEX FLG-NYL LOCK M8X1.25 CL8 Z & Y
-
93020-058 INSULATOR, INTAKEINSULATOR, INTAKE
-
102670-110 TUBE, INTAKETUBE, INTAKE
-
118427-602 NUT,HEX FLG-NYL LOCK M6X1.0 CL8 Z & YNUT,HEX FLG-NYL LOCK M6X1.0 CL8 Z & Y
-
123020-053 GASKET, CARBURETOR/INTAKE TUBEGASKET, CARBURETOR/INTAKE TUBE
-
133020-021 GASKET, INTAKEGASKET, INTAKE
-
143020-022 INSULATOR, CARBURETORINSULATOR, CARBURETOR
