STEERING POST AND TIE ROD ASSEMBLY для Arctic Cat ZR 120 (RUSSIAN) (BLACK) [S2015ZRAAARUB] - 2015 года выпуска
-
№АртикулНазвание
-
11705-313 POST, STEERING (BLACK)POST, STEERING (BLACK)
-
21606-765 GRIP, HANDLEGRIP, HANDLE
-
30302-165 CONTROL, THROTTLECONTROL, THROTTLE
-
41623-828 PIN - 1/4D X 1 5/8PIN - 1/4D X 1 5/8
-
58070-318 PIN,SPRING-3/16 X 1-1/2 SLOTTED P & OPIN,SPRING-3/16 X 1-1/2 SLOTTED P & O
-
60611-022 DECAL, ENGINE STOP SWITCHDECAL, ENGINE STOP SWITCH
-
70109-609 LEVER, CONTROLLEVER, CONTROL
-
80123-231 RING, RETAININGRING, RETAINING
-
90302-147 HOUSING, BRAKEHOUSING, BRAKE
-
100609-007 SWITCH, STOP - ENGINESWITCH, STOP - ENGINE
-
111705-444 COVER, HANDLEBAR PADCOVER, HANDLEBAR PAD
-
121605-107 PAD, HANDLEBARPAD, HANDLEBAR
-
138020-040 SCREW,CAP-HFH 1/4-20 X 0.750 Z & YSCREW,CAP-HFH 1/4-20 X 0.750 Z & Y
-
143008-040 CLAMP, HEAT SENSOR,M12CLAMP, HEAT SENSOR,M12
-
150705-896 BRACKET, STEERING SUPPORT - PAINTED (BLACK)BRACKET, STEERING SUPPORT - PAINTED (BLACK)
-
160605-444 BEARING, STEERING POSTBEARING, STEERING POST
-
178047-366 NUT,HEX FLG-NY LOCK 1/4-20 GR F Z & YNUT,HEX FLG-NY LOCK 1/4-20 GR F Z & Y
-
181623-423 NUT, FLEX-LOC 5/16-24 UNF Z & YNUT, FLEX-LOC 5/16-24 UNF Z & Y
-
198050-247 WASHER,FLAT- 5/16 X .688 X .065 Z & YWASHER,FLAT- 5/16 X .688 X .065 Z & Y
-
208004-135 SCREW,CAP-HH 5/16-24 X1.50 G5 Z & YSCREW,CAP-HH 5/16-24 X1.50 G5 Z & Y
-
211703-853 TIE ROD - ASSEMBLY (INC. 22-23)TIE ROD - ASSEMBLY (INC. 22-23)
-
220623-260 ...NUT, HEX - LEFT-HAND THREAD...NUT, HEX - LEFT-HAND THREAD
-
230123-144 ...NUT, HEX - RIGHT-HAND THREAD...NUT, HEX - RIGHT-HAND THREAD
-
248060-484 RIVET, BLIND-DH SS53 ZINCRIVET, BLIND-DH SS53 ZINC
-
251707-444 SUPPORT, STEERING POST (BLACK)SUPPORT, STEERING POST (BLACK)
-
260630-138 SWITCH, TETHER (INC. 27)SWITCH, TETHER (INC. 27)
-
270630-139 ...CORD, TETHER SWITCH...CORD, TETHER SWITCH
-
280687-229 CABLE, BRAKECABLE, BRAKE
-
291602-100 SPRING, RETURN - BRAKESPRING, RETURN - BRAKE
-
300123-788 TIE, CABLE - 8 IN.TIE, CABLE - 8 IN.
-
310687-231 CABLE, THROTTLE (120) (INC. TWO NO. 32)CABLE, THROTTLE (120) (INC. TWO NO. 32)
-
328053-212 ...WASHER,LOCK-1/4 EXT TOOTH TYP A Z & Y...WASHER,LOCK-1/4 EXT TOOTH TYP A Z & Y
