WINDSHIELD AND INSTRUMENTS ASSEMBLIES для Arctic Cat ZR 7000 SNO PRO (GREEN) [S2015ZRUSPUSG] - 2015 года выпуска
-
№АртикулНазвание
-
14718-386 POD W/ DECALS - (BLACK) (INC. 2-3)POD W/ DECALS - (BLACK) (INC. 2-3)
-
26606-628 ...POD, INSTRUMENT - (BLACK)...POD, INSTRUMENT - (BLACK)
-
31621-494 ...DECAL, POD - RIGHT - (GREEN)...DECAL, POD - RIGHT - (GREEN)
-
31621-495 ...DECAL, POD - LEFT - (GREEN)...DECAL, POD - LEFT - (GREEN)
-
40641-897 OUTLET, ACCESSORY - (12V DC)OUTLET, ACCESSORY - (12V DC)
-
51623-129 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
-
66606-556 VENTVENT
-
70609-911 SWITCH, IGNITION (INC. 8-10)SWITCH, IGNITION (INC. 8-10)
-
80430-050 ...NUT, FLANGE - IGNITION SWITCH...NUT, FLANGE - IGNITION SWITCH
-
90430-042 ...KEY, IGNITION - (Y SERIES - LEFT-SIDE CUT)...KEY, IGNITION - (Y SERIES - LEFT-SIDE CUT)
-
90430-043 ...KEY, IGNITION - (Z SERIES - RIGHT-SIDE CUT)...KEY, IGNITION - (Z SERIES - RIGHT-SIDE CUT)
-
100430-054 ...COVER, KEY...COVER, KEY
-
110720-019 GAUGE, SPEEDOMETERGAUGE, SPEEDOMETER
-
122623-042 SCREW, SHOULDERSCREW, SHOULDER
-
131623-025 INSERTINSERT
-
146606-864 WINDSHIELD - LOW - (TEAM ARCTIC GREEN)WINDSHIELD - LOW - (TEAM ARCTIC GREEN)
-
152623-146 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
