SKID PLATE AND SIDE PANEL ASSEMBLY для Arctic Cat ZR 8000 SNO PRO RR (INTERNATIONAL) (GREEN) - 2015 года выпуска

№

Артикул

Название
1

4718-214 PANEL, SIDE W/DECALS (RR) - RIGHT - (BLACK) (INC. 2-11)

PANEL, SIDE W/DECALS (RR) - RIGHT - (BLACK) (INC. 2-11)

55 320 ₽
2

3718-180 ...PANEL, SIDE W/FOAM - RIGHT - (BLACK) (INC. 3-7)

...PANEL, SIDE W/FOAM - RIGHT - (BLACK) (INC. 3-7)

39 930 ₽
3

0617-626 ......FOAM, SIDE PANEL - UPPER FRONT - RIGHT

......FOAM, SIDE PANEL - UPPER FRONT - RIGHT

650 ₽
4

6606-414 ......FOIL, PROTECTIVE-MIDDLE SIDE PANEL-RIGHT

......FOIL, PROTECTIVE-MIDDLE SIDE PANEL-RIGHT

290 ₽
5

0617-628 ......FOAM, SIDE PANEL - UPPER REAR - RIGHT

......FOAM, SIDE PANEL - UPPER REAR - RIGHT

5 400 ₽
6

0617-632 ......FOAM, SIDE PANEL - LOWER FRONT - RIGHT

......FOAM, SIDE PANEL - LOWER FRONT - RIGHT

3 320 ₽
7

0617-634 ......FOAM, SIDE PANEL - LOWER REAR - RIGHT

......FOAM, SIDE PANEL - LOWER REAR - RIGHT

5 820 ₽
8

1621-354 ...DECAL, SIDE PANEL - UPPER - RIGHT

...DECAL, SIDE PANEL - UPPER - RIGHT

5 610 ₽
9

1621-356 ...DECAL, SIDE PANEL - LOWER - RIGHT

...DECAL, SIDE PANEL - LOWER - RIGHT

5 820 ₽
10

1621-360 ...DECAL, SIDE PANEL - CENTER - RIGHT

...DECAL, SIDE PANEL - CENTER - RIGHT

2 910 ₽
11

1621-358 ...DECAL, SIDE PANEL - FORWARD - RIGHT

...DECAL, SIDE PANEL - FORWARD - RIGHT

2 490 ₽
12

4718-581 PANEL, SIDE W/DECALS - LEFT - (BLACK) (INC. 13-21)

PANEL, SIDE W/DECALS - LEFT - (BLACK) (INC. 13-21)

55 320 ₽
13

4718-553 ...PANEL, SIDE W/FOAM - LEFT - (BLACK) (INC. 14-16)

...PANEL, SIDE W/FOAM - LEFT - (BLACK) (INC. 14-16)

39 930 ₽
14

0617-629 ......FOAM, SIDE PANEL - UPPER REAR - LEFT

......FOAM, SIDE PANEL - UPPER REAR - LEFT

2 490 ₽
15

0617-635 ......FOAM, SIDE PANEL - LOWER REAR - LEFT

......FOAM, SIDE PANEL - LOWER REAR - LEFT

1 870 ₽
16

0617-681 ......FOAM, SIDE PANEL - LOWER FRONT - LEFT

......FOAM, SIDE PANEL - LOWER FRONT - LEFT

860 ₽
17

2621-301 ...DECAL, SIDE PANEL (RR) - UPPER - LEFT

...DECAL, SIDE PANEL (RR) - UPPER - LEFT

11 230 ₽
18

1621-357 ...DECAL, SIDE PANEL - LOWER - LEFT

...DECAL, SIDE PANEL - LOWER - LEFT

6 030 ₽
19

2621-299 ...DECAL, SIDE PANEL (RR) - MID - LEFT

...DECAL, SIDE PANEL (RR) - MID - LEFT

2 700 ₽
20

1621-359 ...DECAL, SIDE PANEL - FORWARD - LEFT

...DECAL, SIDE PANEL - FORWARD - LEFT

2 490 ₽
21

2621-297 ...DECAL, SIDE PANEL (RR) - MID VENT - LEFT

...DECAL, SIDE PANEL (RR) - MID VENT - LEFT

3 740 ₽
22

1623-637 CLIP, U-NUT

CLIP, U-NUT

380 ₽
23

0607-447 CABLE - (5 IN.)

CABLE - (5 IN.)

810 ₽
24

0605-283 CLIP, HAIRPIN

CLIP, HAIRPIN

190 ₽
25

8060-486 RIVET

RIVET

60 ₽
26

8050-127 WASHER

WASHER

210 ₽
27

1623-052 CLIP, U-NUT

CLIP, U-NUT

150 ₽
28

6606-925 SCREEN, INTAKE

SCREEN, INTAKE

5 190 ₽
29

2602-794 DUCT, INTAKE - INNER

DUCT, INTAKE - INNER

4 150 ₽
30

1623-030 CLIP, U-NUT

CLIP, U-NUT

150 ₽
31

2602-793 DUCT, INTAKE - OUTER - (BLACK)

DUCT, INTAKE - OUTER - (BLACK)

2 910 ₽
32

1702-369 DUCT, AIR - CLUTCH

DUCT, AIR - CLUTCH

5 820 ₽
33

6606-694 FOIL, PROTECTIVE - 2 STROKE

FOIL, PROTECTIVE - 2 STROKE

560 ₽
34

0623-797 SCREW, SELF-TAPPING

SCREW, SELF-TAPPING

650 ₽
35

4718-218 PLATE, SKID W/DECALS - RIGHT - (TEAM ARCTIC GREEN) (INC. 36-44)

PLATE, SKID W/DECALS - RIGHT - (TEAM ARCTIC GREEN) (INC. 36-44)

36 390 ₽
36

4718-220 ...PLATE, SKID W/FOAM - RIGHT - (TEAM ARCTIC GREEN) (INC. 37-43)

...PLATE, SKID W/FOAM - RIGHT - (TEAM ARCTIC GREEN) (INC. 37-43)

32 440 ₽
37

0617-640 ......FOAM, SKID PLATE - UPPER REAR - RIGHT

......FOAM, SKID PLATE - UPPER REAR - RIGHT

540 ₽
38

0617-638 ......FOAM, SKID PLATE - CENTER FRONT - RIGHT

......FOAM, SKID PLATE - CENTER FRONT - RIGHT

6 440 ₽
39

0617-636 ......FOAM, SKID PLATE - UPPER FRONT - RIGHT

......FOAM, SKID PLATE - UPPER FRONT - RIGHT

5 400 ₽
40

2612-850 ......FOIL, PROTECTIVE-RESONATOR

......FOIL, PROTECTIVE-RESONATOR

3 110 ₽
41

8061-708 ......RIVET

......RIVET

150 ₽
42

2612-754 ......DEFLECTOR, HEAT - SHIELD

......DEFLECTOR, HEAT - SHIELD

4 360 ₽
43

0123-802 ......WASHER

......WASHER

20 ₽
44

1621-362 ...DECAL, SKID PLATE - RIGHT

...DECAL, SKID PLATE - RIGHT

3 740 ₽
45

4718-219 PLATE, SKID W/DECALS - LEFT - (RR ) (TEAM ARCTIC GREEN) (INC. 46-51)

PLATE, SKID W/DECALS - LEFT - (RR ) (TEAM ARCTIC GREEN) (INC. 46-51)

22 670 ₽
46

4718-221 ...PLATE, SKID W/FOAM - LEFT - (TEAM ARCTIC GREEN) (INC. 47-50)

...PLATE, SKID W/FOAM - LEFT - (TEAM ARCTIC GREEN) (INC. 47-50)

18 920 ₽
47

0617-637 ......FOAM, SKID PLATE - UPPER FRONT - LEFT

......FOAM, SKID PLATE - UPPER FRONT - LEFT

2 490 ₽
48

0617-639 ......FOAM, SKID PLATE - CENTER FRONT - LEFT

......FOAM, SKID PLATE - CENTER FRONT - LEFT

2 490 ₽
49

0617-641 ......FOAM, SKID PLATE - UPPER REAR - LEFT

......FOAM, SKID PLATE - UPPER REAR - LEFT

610 ₽
50

6606-613 ......PANEL, REINFORCEMENT

......PANEL, REINFORCEMENT

1 870 ₽
51

1621-363 ...DECAL, SKID PLATE - LEFT

...DECAL, SKID PLATE - LEFT

3 740 ₽
52

2623-005 CLIP, RETAINING

CLIP, RETAINING

400 ₽
53

6606-592 PIN, RETAINING

PIN, RETAINING

540 ₽
54

1623-129 SCREW, SELF-TAPPING

SCREW, SELF-TAPPING

230 ₽
55

2612-796 PLATE, EXHAUST OUTLET

PLATE, EXHAUST OUTLET

2 070 ₽
56

2612-795 SEAL, EXHAUST OUTLET

SEAL, EXHAUST OUTLET

2 700 ₽
57

8061-710 RIVET, BLIND

RIVET, BLIND

170 ₽
58

6606-295 SHIELD, HEAT - ECM

SHIELD, HEAT - ECM

3 740 ₽
59

8408-620 SCREW, CAP

SCREW, CAP

110 ₽
60

0423-031 CLIP, U-NUT

CLIP, U-NUT

150 ₽
61

0623-784 SCREW, SELF-TAPPING

SCREW, SELF-TAPPING

210 ₽
62

6606-342 FASCIA, FRONT - RIGHT - (BLACK)

FASCIA, FRONT - RIGHT - (BLACK)

2 910 ₽
62

3718-303 FASCIA, FRONT - LEFT - (BLACK) (INC. 63)

FASCIA, FRONT - LEFT - (BLACK) (INC. 63)

2 910 ₽
63

6606-405 ...FOIL, PROTECTIVE, FILLER PANEL - LEFT

...FOIL, PROTECTIVE, FILLER PANEL - LEFT

4 150 ₽
64

2623-001 NUT, PUSH - (3/16 IN.) (OPTIONAL)

NUT, PUSH - (3/16 IN.) (OPTIONAL)

60 ₽
65

1623-999 SCREW, THUMB (OPTIONAL)

SCREW, THUMB (OPTIONAL)

750 ₽
