SUSPENSION FRONT - SHOCK ABSORBER для Arctic Cat ZR 6000 RR GREEN [S2016ZRDRRUSG] - 2016 года выпуска
-
№АртикулНазвание
-
-3703-344 SHOCK ABSORBER - RIGHTSHOCK ABSORBER - RIGHT
-
-3703-345 SHOCK ABSORBER - LEFTSHOCK ABSORBER - LEFT
-
13604-147 RING, RETAININGRING, RETAINING
-
21604-664 BEARINGBEARING
-
33603-385 KNOB, DAMPING ADJUSTER - LOW SPEEDKNOB, DAMPING ADJUSTER - LOW SPEED
-
43603-377 SCREW, MACHINESCREW, MACHINE
-
53603-386 KNOB, DAMPING ADJUSTER - REBOUNDKNOB, DAMPING ADJUSTER - REBOUND
-
63603-367 CAP, AIR VALVECAP, AIR VALVE
-
72603-965 SEALSEAL
-
82603-511 VALVE, AIRVALVE, AIR
-
93603-378 DECAL, RESERVOIRDECAL, RESERVOIR
-
103603-365 DECAL, "PERFORMANCE SERIES"DECAL, "PERFORMANCE SERIES"
-
113603-373 DECAL, "EVOL"DECAL, "EVOL"
-
123603-369 DECAL, "FLOAT 3 FOX"DECAL, "FLOAT 3 FOX"
-
133603-420 KIT, SEAL/BEARING REBUILDKIT, SEAL/BEARING REBUILD
-
144639-012 FLUID, FLOAT SHOCK - 8 OZFLUID, FLOAT SHOCK - 8 OZ
-
155639-530 OIL, SHOCK - 1 QTOIL, SHOCK - 1 QT
