HOOD AND AIR INTAKE ASSEMBLY для Arctic Cat ZR 6000 RS LTD ES 129 BLACK - 2017 года выпуска
-
№АртикулНазвание
-
15718-492 HOOD W/DECALS - RIGHT - BLACK (INC. 2-4)HOOD W/DECALS - RIGHT - BLACK (INC. 2-4)
-
15718-493 HOOD W/DECALS - LEFT - BLACK (INC. 2-4)HOOD W/DECALS - LEFT - BLACK (INC. 2-4)
-
27606-138 ...HOOD W/O DECALS - RIGHT - BLACK...HOOD W/O DECALS - RIGHT - BLACK
-
27606-139 ...HOOD W/O DECALS - LEFT - BLACK...HOOD W/O DECALS - LEFT - BLACK
-
33621-902 ...DECAL, HOOD - FRONT UPPER - RIGHT...DECAL, HOOD - FRONT UPPER - RIGHT
-
33621-903 ...DECAL, HOOD - FRONT UPPER - LEFT...DECAL, HOOD - FRONT UPPER - LEFT
-
43621-904 ...DECAL, HOOD - REAR LOWER - RIGHT...DECAL, HOOD - REAR LOWER - RIGHT
-
43621-905 ...DECAL, HOOD - REAR LOWER - LEFT...DECAL, HOOD - REAR LOWER - LEFT
-
57606-050 PLENUM, AIR INTAKE - LOWER FRONTPLENUM, AIR INTAKE - LOWER FRONT
-
65718-329 PLENUM, AIR INTAKE - LOWER REAR - W/FOIL (INC. 7)PLENUM, AIR INTAKE - LOWER REAR - W/FOIL (INC. 7)
-
77606-307 ...FOIL, PROTECTIVE...FOIL, PROTECTIVE
-
80608-758 SCREEN, INTAKE DUCT - RIGHTSCREEN, INTAKE DUCT - RIGHT
-
80608-759 SCREEN, INTAKE DUCT - LEFTSCREEN, INTAKE DUCT - LEFT
-
90608-748 DUCT, INTAKE - RIGHTDUCT, INTAKE - RIGHT
-
90608-749 DUCT, INTAKE - LEFTDUCT, INTAKE - LEFT
-
103621-916 EMBLEM, HOOD - CENTEREMBLEM, HOOD - CENTER
-
115718-328 PLENUM, INTAKE - UPPER (INC. 22)PLENUM, INTAKE - UPPER (INC. 22)
-
127606-258 VENT - RIGHTVENT - RIGHT
-
127606-259 VENT - LEFTVENT - LEFT
-
136606-386 SEALSEAL
-
141623-939 NUT, UNUT, U
-
151623-933 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
-
167606-056 BEZEL, VENT - RIGHTBEZEL, VENT - RIGHT
-
167606-057 BEZEL, VENT - LEFTBEZEL, VENT - LEFT
-
172623-058 SCREW, SHOULDERSCREW, SHOULDER
-
182623-211 SCREWSCREW
-
192623-004 NUT, PUSHNUT, PUSH
-
202623-003 PIN, RETAININGPIN, RETAINING
-
212623-164 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
-
220617-648 FOAM, INTAKEFOAM, INTAKE
-
231623-929 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
-
248050-217 WASHERWASHER
-
250423-018 CLAMP, HOSECLAMP, HOSE
-
260617-624 ADAPTER, BOOTADAPTER, BOOT
-
271770-056 BOOT, INTAKEBOOT, INTAKE
-
282670-444 BOOTBOOT
-
290824-052 SENSOR, T-MAPSENSOR, T-MAP
-
302623-016 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
