09- Rear Cargo Box _42T1511 для BRP Renegade 500 EFI - 2015
-
№АртикулНазвание
-
4207066044 Hex. Screw M6 X 60Hex. Screw M6 X 60
-
5207685044 Hex. Flanged Screw M8 X 50Hex. Flanged Screw M8 X 50
-
11224061201 Flat WasherFlat Washer
-
12233261414 Hex. Flanged Elastic Nut M6Hex. Flanged Elastic Nut M6
-
13233281414 Hex. Flanged Elastic Nut M8Hex. Flanged Elastic Nut M8
-
15234062410 Flat Washer 6 mm. Model-North America, InternationalFlat Washer 6 mm. Model-North America, International
-
16250000283 Torx Screw M8 X 25, Scotch GripTorx Screw M8 X 25, Scotch Grip
-
17250000298 Torx Truss Screw M8 X 50Torx Truss Screw M8 X 50
-
18250000712 Torx Screw M6 X 20Torx Screw M6 X 20
-
19293450274 InsertInsert
-
27704700148 Tool KitTool Kit
-
29715001894 Kit Rear BumperKit Rear Bumper
-
31704902777 Warning Decal, Luggage RackWarning Decal, Luggage Rack
-
32704902778 Warning Decal, Luggage RackWarning Decal, Luggage Rack
-
34705004977 LH Front BracketLH Front Bracket
-
36705004978 RH Front BracketRH Front Bracket
-
40705004981 Rear TubeRear Tube
-
41705005837 Flag Support. Model-North America, InternationalFlag Support. Model-North America, International
-
52234062410 Flat Washer 6 mm. Model-EuropeFlat Washer 6 mm. Model-Europe
-
53233261414 Hex. Flanged Elastic Nut M6Hex. Flanged Elastic Nut M6
