10- Electrical System _09S1408 для BRP GTX LTD 215 - 2014
-
№АртикулНазвание
-
1207184060 Hex. Screw M8 X 40Hex. Screw M8 X 40
-
2207302060 Hex. Screw M10 X 20, Scotch GripHex. Screw M10 X 20, Scotch Grip
-
3207361260 Hex. Screw M6 X 12, Scotch GripHex. Screw M6 X 12, Scotch Grip
-
4232561200 Elastic Stop Nut M6, BrassElastic Stop Nut M6, Brass
-
5234000600 Flat Washer 10 mm, StainlessFlat Washer 10 mm, Stainless
-
6234061600 Flat Washer M6, StainlessFlat Washer M6, Stainless
-
7234082600 Flat Washer 8 mm, StainlessFlat Washer 8 mm, Stainless
-
8278001882 Battery, 30 AmperesBattery, 30 Amperes
-
9278002278 Ground CableGround Cable
-
10278002279 Starter CableStarter Cable
-
11278002283 RH Throttle SensorRH Throttle Sensor
-
12278002284 LH Throttle SensorLH Throttle Sensor
-
13278002339 Battery SupportBattery Support
-
14278002602 SwitchSwitch
-
15278002676 Switch Start / StopSwitch Start / Stop
-
16278002767 SwitchSwitch
-
18278002856 Housing JAE, 2 CircuitsHousing JAE, 2 Circuits
-
19278003011 Wiring HarnessWiring Harness
-
20278002950 Wiring Harness Ass'yWiring Harness Ass'y
-
21278002963 Safety NutSafety Nut
-
23278003048 SupportSupport
-
25293750053 Tie Rap 300mmTie Rap 300mm
-
26295500849 Battery Fastener KitBattery Fastener Kit
-
27414115200 Tie-Rap 180 mmTie-Rap 180 mm
-
28278003012 Starter RelayStarter Relay
-
29278002704 Diagnostic ConnectorDiagnostic Connector
-
30293750008 Tie-Rap 350 mmTie-Rap 350 mm
-
31278003097 SpeedometerSpeedometer
-
32278003053 O.T.A.S ActuatorO.T.A.S Actuator
-
33278003008 O.T.A.S. SensorO.T.A.S. Sensor
-
34278002484 Safety Lanyard, Learning KeySafety Lanyard, Learning Key
-
34278003010 Safety Lanyard, AntitheftSafety Lanyard, Antitheft
-
35710001103 Voltage RegulatorVoltage Regulator
-
36278003009 O.T.A.S. Sensor Ass'yO.T.A.S. Sensor Ass'y
