09- Luggage Rack для BRP Ski-Doo GSX LE 600HOETEC XP - 2012
-
№АртикулНазвание
-
1511000757 TrunkTrunk
-
2511000528 BracketBracket
-
3a511000568 Trunk CoverTrunk Cover
-
6511000483 RH Tunnel RailRH Tunnel Rail
-
7293150104 Pop Rivet 3/16''Pop Rivet 3/16''
-
8520000889 Anchor LinkAnchor Link
-
9250000325 Torx Screw M6 X 12Torx Screw M6 X 12
-
10511000484 LH Tunnel RailLH Tunnel Rail
-
11293150104 Pop Rivet 3/16''Pop Rivet 3/16''
-
12520000889 Anchor LinkAnchor Link
-
13250000325 Torx Screw M6 X 12Torx Screw M6 X 12
-
14860200412 BagBag
