HANDLEBAR для Kawasaki KLX 125L - 2004 года выпуска
-
№АртикулНазвание
-
1307013070-S008 GUIDE, CABLEGUIDE, CABLE
-
3909239092-S004 PIN, HAIR, FRONT FOOTREST COTTERPIN, HAIR, FRONT FOOTREST COTTER
-
4600346003-S003-530 HANDLE (B.SILVER)HANDLE (B.SILVER)
-
5401154011-S001 CABLE, CLUTCHCABLE, CLUTCH
-
5401254012-S004 CABLE, THROTTLECABLE, THROTTLE
-
9204392043-S021 PIN, CLUTCH CABLEPIN, CLUTCH CABLE
-
9215392153-S011 BOLTBOLT
-
9217192171-S051 CLAMP, L=90CLAMP, L=90
-
92171A92171-S065 CLAMPCLAMP
