FRAME для Kawasaki KX250F (KX250YBF) - 2011 года выпуска
-
№АртикулНазвание
-
3216032160-0403 FRAME-COMP, FRONTFRAME-COMP, FRONT
-
32160A32160-0463 FRAME-COMP, REARFRAME-COMP, REAR
-
9201592015-1791 NUT, POP, 6MM, L=15NUT, POP, 6MM, L=15
-
92015A92015-1792 NUT, POP, 6MM, L=16.5NUT, POP, 6MM, L=16.5
-
92015B92015-1861 NUT, STEERING STEM, 28MMNUT, STEERING STEM, 28MM
-
9202292022-250 WASHER, 25X36X2.3WASHER, 25X36X2.3
-
9211692116-1069 BEARING-ROLLER, HI-CAP32006JREARSBEARING-ROLLER, HI-CAP32006JREARS
-
92116A92116-1076 BEARING-ROLLER, HI-CAP320/28JREARBEARING-ROLLER, HI-CAP320/28JREAR
-
9215092150-1760 BOLT, SOCKET, 8X20BOLT, SOCKET, 8X20
-
9215492154-0024 BOLT, SOCKET, 8X32BOLT, SOCKET, 8X32
-
9221092210-0066 NUT, 24MMNUT, 24MM
