FUEL EVAPORATIVE SYSTEM (CALIF ONLY) для Kawasaki NINJA 250R - 2002 года выпуска
-
№АртикулНазвание
-
1101211012-1388 CAP, CANISTER (CALIF. ONLY)CAP, CANISTER (CALIF. ONLY)
-
1104611046-1238 BRACKET, CANISTER (CALIF. ONLY)BRACKET, CANISTER (CALIF. ONLY)
-
1616416164-1054 CANISTER (CALIF. ONLY)CANISTER (CALIF. ONLY)
-
1616516165-1001 SEPARATOR (CALIF. ONLY)SEPARATOR (CALIF. ONLY)
-
2112621126-008 CLAMP, WIRING HARNESS (CALIF. ONLY)CLAMP, WIRING HARNESS (CALIF. ONLY)
-
9203792037-1104 CLAMP, HOSE (CALIF. ONLY)CLAMP, HOSE (CALIF. ONLY)
-
92037A92037-147 CLAMP, TUBE (CALIF. ONLY)CLAMP, TUBE (CALIF. ONLY)
-
92037B92037-1512 CLAMP, CANISTER (CALIF. ONLY)CLAMP, CANISTER (CALIF. ONLY)
-
9205992059-1496 TUBE, 5X10X170 (BLUE) (CALIF. ONLY)TUBE, 5X10X170 (BLUE) (CALIF. ONLY)
-
92059A92059-1568 TUBE, 4X9X420 (WHITE) (CALIF. ONLY)TUBE, 4X9X420 (WHITE) (CALIF. ONLY)
-
92059B92059-1806 TUBE, 7X12X830 (GREEN) (CALIF. ONLY)TUBE, 7X12X830 (GREEN) (CALIF. ONLY)
-
92059C92059-1808 TUBE, 5X10X610 (BLUE) (CALIF. ONLY)TUBE, 5X10X610 (BLUE) (CALIF. ONLY)
-
92059D92059-1952 TUBE, 5X10X640 (RED) (CALIF. ONLY)TUBE, 5X10X640 (RED) (CALIF. ONLY)
-
9207292072-1188 BAND, L=150 (CALIF. ONLY)BAND, L=150 (CALIF. ONLY)
-
92072A92072-1419 BAND, L=50 (CALIF. ONLY)BAND, L=50 (CALIF. ONLY)
