HANDLEBAR для Kawasaki NINJA ZX-6RR - 2003 года выпуска
-
№АртикулНазвание
-
120120S0620 BOLT, SOCKET, 6X20BOLT, SOCKET, 6X20
-
120A120S0835 BOLT, SOCKET, 8X35 (BLACK)BOLT, SOCKET, 8X35 (BLACK)
-
220220C0525 SCREW, PAN, CROSSCREW, PAN, CROS
-
220A220C0535 SCREW, PAN, CROSSCREW, PAN, CROS
-
221221C0316 SCREW, CSK, CROSSCREW, CSK, CROS
-
236236C0410 SCREW, PAN, WSP, CROS, 4X10SCREW, PAN, WSP, CROS, 4X10
-
1304213042-1133 WEIGHT, HANDLEWEIGHT, HANDLE
-
1316813168-1516 LEVER, CHOKELEVER, CHOKE
-
1328013280-0034 HOLDER, CLUTCH LEVERHOLDER, CLUTCH LEVER
-
13280A13280-0035 HOLDER, CLUTCH LEVERHOLDER, CLUTCH LEVER
-
2701027010-1492 SWITCH, CLUTCHSWITCH, CLUTCH
-
3209932099-1193 CASE, THROTTLE CABLECASE, THROTTLE CABLE
-
4600346003-1590 HANDLE (LEFT)HANDLE (LEFT)
-
46003A46003-1591 HANDLE (RIGHT)HANDLE (RIGHT)
-
4601946019-0001 GRIP, ASSY., THROTTLEGRIP, ASSY., THROTTLE
-
4607546075-1144 GRIP (LEFT)GRIP (LEFT)
-
4607646076-1255 LEVER, ASSY., GRIP, CLUTCHLEVER, ASSY., GRIP, CLUTCH
-
4609146091-1889 HOUSING, ASSY., CONTROL (RIGHT)HOUSING, ASSY., CONTROL (RIGHT)
-
46091A46091-1892 HOUSING, ASSY., CONTROL (LEFT)HOUSING, ASSY., CONTROL (LEFT)
-
4609246092-0002 LEVER, GRIP, CLUTCHLEVER, GRIP, CLUTCH
-
9203392033-1102 RING, SNAP, OD=22.2RING, SNAP, OD=22.2
-
9209292092-1075 BUSHING, RUBBER, HANDLEBUSHING, RUBBER, HANDLE
-
9214392143-1351 COLLARCOLLAR
-
9214592145-1286 SPRINGSPRING
-
9215092150-1090 BOLT, 6MMBOLT, 6MM
-
92150A92150-1604 BOLT, SOCKET, 8X30BOLT, SOCKET, 8X30
-
9215192151-1523 BOLTBOLT
-
9217292172-1060 SCREW, ADJUST NUTSCREW, ADJUST NUT
-
9221092210-0006 NUT, LOCK, 6MMNUT, LOCK, 6MM
