BRAKE PEDAL для Kawasaki VULCAN S (EN650CHF) - 2017 года выпуска
-
№АртикулНазвание
-
180180BB0614 BOLT-UPSET-WS, 6X14BOLT-UPSET-WS, 6X14
-
3915639156-1641 PADPAD
-
4300143001-0733 LEVER-BRAKE, PEDALLEVER-BRAKE, PEDAL
-
9200992009-1677 SCREW, 6X8SCREW, 6X8
-
9202292022-1392 WASHER, 7X28X1.6, (BLACK)WASHER, 7X28X1.6, (BLACK)
-
9214592145-1158 SPRING, BRAKE PEDAL RETURNSPRING, BRAKE PEDAL RETURN
