BRAKE - REAR W/ HUBS для Kawasaki TERYX4 CAMO (KRT800HKF) - 2019 года выпуска
-
№АртикулНазвание
-
1101211012-1969 CAP, WHEELCAP, WHEEL
-
4903049030-0563 HUB, REARHUB, REAR
-
550550AA4030 PIN-COTTER, 4.0X30PIN-COTTER, 4.0X30
-
9215292152-1700 COLLAR, 30.1X44X9COLLAR, 30.1X44X9
-
9215392153-1915 BOLT, 12MMBOLT, 12MM
-
9220092200-1739 WASHER, 20.3X52.0X4.5WASHER, 20.3X52.0X4.5
-
9221092210-2093 NUT, FLANGED, 20MMNUT, FLANGED, 20MM
