EXHAUST CONTROL для Ktm 250 SX - 2002 года выпуска
-
№АртикулНазвание
-
10965050103 FLAT HEAD SCREW DIN0965-M 5X10FLAT HEAD SCREW DIN0965-M 5X10
-
254637062000 RETAINING PLATE R/SRETAINING PLATE R/S
-
354637063000 RETAINING PLATE L/SRETAINING PLATE L/S
-
40770160021 O-RING 16,00X2,00 VITONO-RING 16,00X2,00 VITON
-
554637061444 CONTROL ROLLER L/S LCONTROL ROLLER L/S L
-
654637061544 CONTROL ROLLER CPL. R/SCONTROL ROLLER CPL. R/S
-
80007050160 CYLINDER PIN DIN0007- 5X16CYLINDER PIN DIN0007- 5X16
-
100912060203 AH SCREW D1N0912-M 6X20AH SCREW D1N0912-M 6X20
-
1154637067000 SPRING SLEEVESPRING SLEEVE
-
1254637066000 OVERLOAD SPRINGOVERLOAD SPRING
-
1354637085300 RETAIN.PLATE CONTROL FLAP '92RETAIN.PLATE CONTROL FLAP '92
-
1454637065000 CONTROL LEVER WITH BALL TYPECONTROL LEVER WITH BALL TYPE
-
1554637068100 BEARING SLEEVEBEARING SLEEVE
-
1654637064000 GEAR SEGMENT R/SGEAR SEGMENT R/S
-
1754637064050 GEAR SEGMENT L/S M6GEAR SEGMENT L/S M6
-
1854737019000 BEAR. SLEEVE F. CONTROL FLAPBEAR. SLEEVE F. CONTROL FLAP
-
190770150151 O-RING 15,00X1,50 VITONO-RING 15,00X1,50 VITON
-
2054637220100 CONTROL FLAPCONTROL FLAP
-
210912060163 AH SCREW DIN0912-M6X16AH SCREW DIN0912-M6X16
-
2254637056000 WASHER 6,5X11X2WASHER 6,5X11X2
-
230984060063 AH SCREW DIN7984-M 6X 6AH SCREW DIN7984-M 6X 6
-
250015050123 HH COLLAR SCREW M 5X12 WS=8HH COLLAR SCREW M 5X12 WS=8
-
260349000050 WASHER DIN7349-5X15X2WASHER DIN7349-5X15X2
-
2754635005000 WATER PUMP WHEELWATER PUMP WHEEL
-
280760082472 SHAFT SEAL RING 8X24X7 A DUOSHAFT SEAL RING 8X24X7 A DUO
-
290137060003 SPRING WASHER D1N0137-B 6SPRING WASHER D1N0137-B 6
-
300625160026 BALL BEARING 16002BALL BEARING 16002
-
3154637050344 CENTRIFUGAL TIMER CPL.CENTRIFUGAL TIMER CPL.
-
3654637098000 GROOVED BALL BEAR. 626.2RS1.C3GROOVED BALL BEAR. 626.2RS1.C3
-
400015050203 HH COLLAR SCREW M 5X20 WS=8HH COLLAR SCREW M 5X20 WS=8
-
4154637070100 COVER LIDCOVER LID
-
4354637075100 SPRING GUIDESPRING GUIDE
-
440770021120 O-RING 12,37X2,62 NBR70O-RING 12,37X2,62 NBR70
-
450770240020 O-RING 24,00X2,00 NBR70O-RING 24,00X2,00 NBR70
-
4654637072000 ADJUST.SPRING L=65MM D=1,8MMADJUST.SPRING L=65MM D=1,8MM
-
4754637072500 AUXILIARY SPRING 1,2MMAUXILIARY SPRING 1,2MM
-
4854637071200 SPRING INSERT '91SPRING INSERT '91
-
5054637055244 ANGLE LEVER CPL. '91ANGLE LEVER CPL. '91
-
510988101610 SHIM WASHER D1N988 1OX16X1,0SHIM WASHER D1N988 1OX16X1,0
-
5254637059244 BEARING SUPPORT CPL.BEARING SUPPORT CPL.
-
5354637057200 CONTROL LEVER '91CONTROL LEVER '91
-
550912050163 AH SCREW DIN0912-M 5X16AH SCREW DIN0912-M 5X16
-
6054637095544 CONNECT ROD CPL.250 L=96MMCONNECT ROD CPL.250 L=96MM
-
6150237195055 SECURING DIN-71805-S-8SECURING DIN-71805-S-8
