CRANKSHAFT W/ PISTON для Ktm 450 SX RFS - 2004 года выпуска
-
№АртикулНазвание
-
159430018000 CRANKSHAFT (STROKE=63,4, WITHOUT WASHER)CRANKSHAFT (STROKE=63,4, WITHOUT WASHER)
-
259430015044 CON.ROD REP.SET (WITH WASHER)CON.ROD REP.SET (WITH WASHER)
-
450330082000 CYL.ROLLER BEAR.NJ206 ET2XCS46CYL.ROLLER BEAR.NJ206 ET2XCS46
-
559030055000 DRIVE GEAR 32-T FBA/ANC SHAFTDRIVE GEAR 32-T FBA/ANC SHAFT
-
656030081000 THRUST WASHER 30,5X45X0,10THRUST WASHER 30,5X45X0,10
-
656030081100 THRUST WASHER 30,7X47X0,15THRUST WASHER 30,7X47X0,15
-
656030081200 THRUST WASHER 30,5X45X0,30THRUST WASHER 30,5X45X0,30
-
70888030050 WOODRUFF KEY DIN6888-3X5X13WOODRUFF KEY DIN6888-3X5X13
-
80984060162 AH SCREW DIN7984-M 6X16AH SCREW DIN7984-M 6X16
-
90760304772 SH.SEAL RING 30X47X7 BSL VITONSH.SEAL RING 30X47X7 BSL VITON
-
1359032000033 PRIMARY GEAR 33-TPRIMARY GEAR 33-T
-
140912060106 AH SCREW DIN0912-M 61(10 10.9AH SCREW DIN0912-M 61(10 10.9
-
1559030029100 HH NUR M20X1,5 WS=27 LEFTHH NUR M20X1,5 WS=27 LEFT
-
166946005 WOODRUFF KEY 5X6,5 HARDERWOODRUFF KEY 5X6,5 HARDER
-
170760142460 SHAFT SEAL RING 14X24X6 BSHAFT SEAL RING 14X24X6 B
-
180471250120 CIRCLIP DIN0471-25X1,2CIRCLIP DIN0471-25X1,2
-
2049030021000 COLLAR NUT M12X1 R/SCOLLAR NUT M12X1 R/S
-
210137120000 SPRING WASHER DIN0137-B12SPRING WASHER DIN0137-B12
-
3359030033000 PISTON PIN BOLT 20X15,8/12X50PISTON PIN BOLT 20X15,8/12X50
-
3459430074000 CIRCLIP 20 X 1,6CIRCLIP 20 X 1,6
-
4059430107000I PISTON CPL.450 SX D=95 51.1PISTON CPL.450 SX D=95 51.1
-
4059430107000II PISTON CPL.450 5X D=95 S1.2PISTON CPL.450 5X D=95 S1.2
-
5158030631000 OIL SCRAPER RING 95MMOIL SCRAPER RING 95MM
-
5259030032000 RECTANGULAR RING 95/87,2X1,25RECTANGULAR RING 95/87,2X1,25
-
5359430070000 FLYWHEEL MASSFLYWHEEL MASS
