HAND BRAKE CYLINDER для Ktm 525 SMR - 2004 года выпуска
-
№АртикулНазвание
-
158713001000 HANDBRAKE CYL.DUKE ADJUST.HANDBRAKE CYL.DUKE ADJUST.
-
258713002000 HAND BRAKE LEVER LOOSE ADJUST.HAND BRAKE LEVER LOOSE ADJUST.
-
458713004000 COVERING CAP FOR LEVER SCREWCOVERING CAP FOR LEVER SCREW
-
958313009000 RUBBER BOOTRUBBER BOOT
-
1159413011000 BRAKE HOSE FR. SMR L=1130MMBRAKE HOSE FR. SMR L=1130MM
-
1258313012000 COVER BREMBOCOVER BREMBO
-
1554413015000 LEVER SCREW CPL.LEVER SCREW CPL.
-
2550213025000 HOLLOW SCREW M10X1X19HOLLOW SCREW M10X1X19
-
2642013026000 CU-SEAL RING DIN7603-10X16X1,5CU-SEAL RING DIN7603-10X16X1,5
-
2742013226000 CU-SEAL RING DIN7603-10X16X1CU-SEAL RING DIN7603-10X16X1
-
330965050163 FLAT HEAD SCREW DIN0965-M 5X16FLAT HEAD SCREW DIN0965-M 5X16
-
350015060203 HH COLLAR SCREW M 6X20 WS=8HH COLLAR SCREW M 6X20 WS=8
-
4058012040050 CLAMP MIRROW M10X1,25CLAMP MIRROW M10X1,25
-
5058313050100 REPAIR KIT CPL. D=13MMREPAIR KIT CPL. D=13MM
-
60306054 BRAKE FLUID DOT 5.1BRAKE FLUID DOT 5.1
