MONOSHOCK - DISASSEMBLED для Ktm 85 SX - 2006 года выпуска
-
№АртикулНазвание
-
146180348 SHOCK ABSORBER TOP H40 135DEG.SHOCK ABSORBER TOP H40 135DEG.
-
250180213S6 DCC-COMPR.DAMP.CONTROL CPL.DCC-COMPR.DAMP.CONTROL CPL.
-
346180007 ADAPTOR BUSH KGW 12X24ADAPTOR BUSH KGW 12X24
-
446180003 OIL SEAL KGW D=25OIL SEAL KGW D=25
-
550180168 WASHER KGW D=25WASHER KGW D=25
-
650180005 BUSHING KGW 1525 HDBUSHING KGW 1525 HD
-
850180095 BLEED PLUG R 1/8BLEED PLUG R 1/8
-
1252000014 STICKER WP 35X55STICKER WP 35X55
-
1350180266 RES. SCREW L=113,5 D=52 BLACKRES. SCREW L=113,5 D=52 BLACK
-
1446180014 O-RING VITON 41X5O-RING VITON 41X5
-
1546180002 SEPARATION PISTON D=52, H=32SEPARATION PISTON D=52, H=32
-
1646180015 PISTON RING 3,9X1,5X156PISTON RING 3,9X1,5X156
-
1850180344 RESERVOIR CAP D=58RESERVOIR CAP D=58
-
1946810893 O-RING NBR 5,28X1,78O-RING NBR 5,28X1,78
-
2036120151 SCREW PLUG M5X6SCREW PLUG M5X6
-
2146811208 RUBBER CAP "DO NOT OPEN"RUBBER CAP "DO NOT OPEN"
-
2546810016 O-RING NBR 48X2O-RING NBR 48X2
-
2746180340 SLEEVE D=48SLEEVE D=48
-
2946180352 LOCK WASHER M52X1,5LOCK WASHER M52X1,5
-
3046180345 TUBE M52X1,5TUBE M52X1,5
-
3546180353 SPRING RETAINER M52X1,5SPRING RETAINER M52X1,5
-
360912050253 AH SCREW DIN0912-M 5X25AH SCREW DIN0912-M 5X25
-
4091010273 SPRING 215 35 N/MM D=9,25 ORANSPRING 215 35 N/MM D=9,25 ORAN
-
4346180349 SPRING WASHER H=15 D=28SPRING WASHER H=15 D=28
-
4546180356 PISTON ROD NUT M10X1PISTON ROD NUT M10X1
-
4646810035 O-RING VITON 37,82X1,78O-RING VITON 37,82X1,78
-
4746811206 PISTON RING 8X46PISTON RING 8X46
-
4836120349 SHIM 10X19X0,30SHIM 10X19X0,30
-
4850180032 SHIM 15X25X0,25SHIM 15X25X0,25
-
4850180395 RING 10X16X1RING 10X16X1
-
4914460016 PISTON + PISTON SPRINGPISTON + PISTON SPRING
-
5036120312 SHIM 10X16X0,30SHIM 10X16X0,30
-
5036120334 SHIM 10X21X0,20SHIM 10X21X0,20
-
5036120335 SHIM 10X23X0,20SHIM 10X23X0,20
-
5036120336 SHIM 10X25X0,20SHIM 10X25X0,20
-
5036120337 SHIM 10X27X0,20SHIM 10X27X0,20
-
5036120338 SHIM 10X29X0,20SHIM 10X29X0,20
-
5036120339 SHIM 10X31X0,20SHIM 10X31X0,20
-
5146180339 SEPARATION BUSH 17X12X18SEPARATION BUSH 17X12X18
-
5446810492 SHIM 12X28X0,20SHIM 12X28X0,20
-
5446810493 SHIM 12X30X0,20SHIM 12X30X0,20
-
5446810494 SHIM 12X32X0,20SHIM 12X32X0,20
-
5446810495 SHIM 12X34X0,20SHIM 12X34X0,20
-
5446810496 SHIM 12X36X0,20SHIM 12X36X0,20
-
5446810518 SHIM 12X26X0,15SHIM 12X26X0,15
-
5446810519 SHIM 12X28X0,15SHIM 12X28X0,15
-
5446810637 BACKPLATE 12X17X0,30BACKPLATE 12X17X0,30
-
5646810492 SHIM 12X28X0,20SHIM 12X28X0,20
-
5646810493 SHIM 12X30X0,20SHIM 12X30X0,20
-
5646810494 SHIM 12X32X0,20SHIM 12X32X0,20
-
5646810520 SHIM 12X30X0,15SHIM 12X30X0,15
-
5646810521 SHIM 12X32X0,15SHIM 12X32X0,15
-
5646810522 SHIM 12X34X0,15SHIM 12X34X0,15
-
5646810523 SHIM 12X36X0,15SHIM 12X36X0,15
-
5646810524 SHIM 12X38X0,15SHIM 12X38X0,15
-
5646810525 SHIM 12X40X0,15SHIM 12X40X0,15
-
5646810637 BACKPLATE 12X17X0,30BACKPLATE 12X17X0,30
-
5746180179 REBOUND DISC H=0REBOUND DISC H=0
-
5746180337 REBOUND DISC H=4REBOUND DISC H=4
-
5846180441 PISTON 5X4,5X/6X6PISTON 5X4,5X/6X6
-
6046180343 TAP PISTON ROD D=13,5TAP PISTON ROD D=13,5
-
6146180342 SPINDEL D=18 LC=159SPINDEL D=18 LC=159
-
6250180397 O-RING VITON 5X1,5O-RING VITON 5X1,5
-
6446180346 NEEDLE REBOUND L=169NEEDLE REBOUND L=169
-
6546180018 O-RING NBR 7,5X2O-RING NBR 7,5X2
-
6646180350 NEEDLE GUIDENEEDLE GUIDE
-
7246180341S ADAPTOR CPL. D=46 H=28 D=38ADAPTOR CPL. D=46 H=28 D=38
-
7646180355 RESERVOIR CAP M16X1RESERVOIR CAP M16X1
-
7746180013 O-RING NBR 12X1O-RING NBR 12X1
-
7850180222 O-RING NBR 4X1,5O-RING NBR 4X1,5
-
7948600028 SPRING D=2,9 L=7,9SPRING D=2,9 L=7,9
-
8040540603 STEEL BALL D=3MMSTEEL BALL D=3MM
-
8146180006 ADJUSTING SCREW L=15,5ADJUSTING SCREW L=15,5
-
8246180016 ADJUSTING ADAPTOR REBOUNDADJUSTING ADAPTOR REBOUND
-
8350180410 INTERM.RING D=58INTERM.RING D=58
-
8546810010 CIRCLIP 49X1,5CIRCLIP 49X1,5
-
8646180338 CAP D=46 H=9,5CAP D=46 H=9,5
-
8750180276 BUMP RUBBER WP60 D=18-26BUMP RUBBER WP60 D=18-26
-
8850180283 CONTRA NUT M18X1 H=5CONTRA NUT M18X1 H=5
-
9046180347 SHOCK ABSORBER BOT. KGW L=54,5SHOCK ABSORBER BOT. KGW L=54,5
-
9850180466S1 SHOCK ABSORBER FLUID 5 LTSHOCK ABSORBER FLUID 5 LT
