STOP DISC для Ktm 105 SX - 2009 года выпуска
-
№АртикулНазвание
-
3147033040000 STOP DISC 15X25X1STOP DISC 15X25X1
-
480471190120 CIRCLIP DIN0471-19X1,2CIRCLIP DIN0471-19X1,2
-
5047033050000 KICKSTART SHAFT 85 SXKICKSTART SHAFT 85 SX
-
5147033051000 KICKSTART GEAR 85 SXKICKSTART GEAR 85 SX
-
5247033052000 RATCHET GEAR 85 SXRATCHET GEAR 85 SX
-
5347033053000 KICKST. INTERMEDIATE GEARDKICKST. INTERMEDIATE GEARD
-
5447033054000 KICKSTART SPRING 85 SXKICKSTART SPRING 85 SX
-
5546033055000 DRIVING HUBDRIVING HUB
-
5647033056000 RATCHET GEAR SPRING 85 SXRATCHET GEAR SPRING 85 SX
-
5947033059000 SPRING SPACER 85 SXSPRING SPACER 85 SX
-
680760142460 SHAFT SEAL RING 14X24X6 BSHAFT SEAL RING 14X24X6 B
-
7047033070000 KICKSTARTER CPL. 85 SXKICKSTARTER CPL. 85 SX
-
750015060163 HH COLLAR SCREW M 6X16HH COLLAR SCREW M 6X16
-
760015050253 HH COLLAR SCREW M 5X25HH COLLAR SCREW M 5X25
Все узлы модели:
- ACCESSORIES KIT
- AIR FILTER
- BRAKE CALIPER FRONT
- BRAKE CALIPER REAR
- CARBURETOR
- CLUTCH
- COOLING SYSTEM
- CRANKSHAFT
- CYLINDER
- DECAL
- ENGINE CASE
- EXHAUST CONTROL
- EXHAUST SYSTEM
- FRAME
- FRONT FORK
- FRONT FORK DISASSEMBLED
- FRONT WHEEL
- HAND BRAKE CYLINDER
- HANDLEBAR CONTROLS
- IGNITION SYSTEM
- MASK FENDERS
- MONOSHOCK DISASSEMBLED
- REAR BRAKE CONTROL
- REAR WHEEL
- REED VALVE CASE
- SHIFTING MECHANISM
- SPECIAL TOOLS - ENGINE
- • STOP DISC
- SWING ARM
- TANK SEAT COVER
- TRANSMISSION I - MAIN SHAFT
- TRANSMISSION II - COUNTERSHAFT
