LUBRICATING SYSTEM для Ktm 250 XC-FW USA - 2009 года выпуска

№

Артикул

Название
1

77038102000 OIL PUMP SHAFT EXC-F

OIL PUMP SHAFT EXC-F

4 560 ₽
2

59038011010 OILPUMP ROTOR CPL. 10MM G-73R

OILPUMP ROTOR CPL. 10MM G-73R

7 510 ₽
3

77038011000 OILPUMP ROTOR 15MM G-164

OILPUMP ROTOR 15MM G-164

11 800 ₽
4

77038001100 OIL PUMP GEAR 14T

OIL PUMP GEAR 14T

1 780 ₽
5

77038004000 OIL PUMP COVER L/S

OIL PUMP COVER L/S

2 860 ₽
6

77038003100 OIL PUMP COVER R/S

OIL PUMP COVER R/S

3 070 ₽
7

0025050166 HH COLLAR SCREW M5X16

HH COLLAR SCREW M5X16

290 ₽
8

0984050122 AH SCREW DIN6912-M 5X12

AH SCREW DIN6912-M 5X12

440 ₽
11

59038041000 OIL FILTER COVER RACING

OIL FILTER COVER RACING

3 240 ₽
12

77038005044 OIL FILTER WITH GASKET

OIL FILTER WITH GASKET

2 290 ₽
14

0402251980 NEEDLEROL.DIN5402 NRA 2,5X19,8

NEEDLEROL.DIN5402 NRA 2,5X19,8

210 ₽
15

0402251180 NEEDLE ROLLER DIN5402 2,5X11,8

NEEDLE ROLLER DIN5402 2,5X11,8

210 ₽
17

77038006100 OILPUMP IDLER GEAR

OILPUMP IDLER GEAR

2 280 ₽
18

0988121805 SHIM WASHER DIN0988-12X18X0,50

SHIM WASHER DIN0988-12X18X0,50

410 ₽
19

0471120010 CIRCLIP DIN0471-12X1

CIRCLIP DIN0471-12X1

30 ₽
20

0770400025 O-RING 40,00X2,50 NBR 70

O-RING 40,00X2,50 NBR 70

290 ₽
21

59038017000 PLUG M20X1,5 WS=13

PLUG M20X1,5 WS=13

1 810 ₽
22

59038016000 OIL SCREEN 15X83MM

OIL SCREEN 15X83MM

3 620 ₽
23

0770125015 O-RING 12,5X1,5 NBR

O-RING 12,5X1,5 NBR

290 ₽
24

0770020170 O-RING 17,17X1,78 GLO

O-RING 17,17X1,78 GLO

470 ₽
25

58038007755 STOP DISK 8,1 X 15 X 0,5

STOP DISK 8,1 X 15 X 0,5

290 ₽
26

0799060000 TAB WASHER DIN6799-RS 6,0

TAB WASHER DIN6799-RS 6,0

290 ₽
28

0770320020 O-RING 32,00X2,00

O-RING 32,00X2,00

350 ₽
29

0025050206 HH COLLAR SCREW M5X20

HH COLLAR SCREW M5X20

350 ₽
