CLUTCH для Ktm 50 SX Mini - 2009 года выпуска
-
№АртикулНазвание
-
145232000033 CLUTCH CPL.CLUTCH CPL.
-
245232011000 CLUTCH BLOCKCLUTCH BLOCK
-
345232007000 DISTANCE SHIM 9,5X19X1,7DISTANCE SHIM 9,5X19X1,7
-
345232007020 DISTANCE SHIM 9,5X19X0,2DISTANCE SHIM 9,5X19X0,2
-
345232007050 DISTANCE SHIM 9,5X19X0,5DISTANCE SHIM 9,5X19X0,5
-
445232005000 CLUTCH SPRINGCLUTCH SPRING
-
545232006000 COLLAR SCREW M6X8COLLAR SCREW M6X8
-
80402182412 NEEDLE BEARING 18X24X12ANEEDLE BEARING 18X24X12A
-
945232013000 INNER RING WITH COLLARINNER RING WITH COLLAR
-
1045232001000 OUT. CLUTCH HUB LOOSEOUT. CLUTCH HUB LOOSE
-
1145232008000 WASHER 8,5X31X4WASHER 8,5X31X4
-
120933080203 HH SCREW DIN0933-M 8X20HH SCREW DIN0933-M 8X20
