BALANCER SHAFT для Ktm 990 ADVENTURE R - 2009 года выпуска
-
№АртикулНазвание
-
160036073150 HEXAGON NUT M20X1,5 H=6MMHEXAGON NUT M20X1,5 H=6MM
-
260033043000 STOP DISK 20,2 X 34 X 1STOP DISK 20,2 X 34 X 1
-
360036081000 SPREAD TRANSMISSIONSPREAD TRANSMISSION
-
4*61136074150 BALANCER WEIGHT R/SBALANCER WEIGHT R/S
-
50888040050 WOODRUFF KEY DIN6888 4X5X13WOODRUFF KEY DIN6888 4X5X13
-
660036014018 TIMING GEAR 18-TTIMING GEAR 18-T
-
70888030037 WOODRUFF KEY DIN6888-3X3,7WOODRUFF KEY DIN6888-3X3,7
-
8*61136073000 TIMING VALVE JACKSHAFT CPL.TIMING VALVE JACKSHAFT CPL.
-
960030024100 CYL. ROLLER BEAR. NUP 204ECYL. ROLLER BEAR. NUP 204E
-
1060030021000 CYL.ROLLER BEARING 26,5X47X14CYL.ROLLER BEARING 26,5X47X14
-
110760122050 SHAFT SEAL RING 12X20X5 BSHAFT SEAL RING 12X20X5 B
-
120093463006 SPRING WASH. 30,5X46,5X0,6-1,5SPRING WASH. 30,5X46,5X0,6-1,5
-
1360036083035 CLAMPING WHEEL 35-ZCLAMPING WHEEL 35-Z
-
1460036081050 TENSION SPRINGTENSION SPRING
-
1560036082035 DRIVE WHEEL 35-TDRIVE WHEEL 35-T
