CLUTCH для Ktm 85 SX 19/16 - 2014 года выпуска
-
№АртикулНазвание
-
147032001244 OUTER CLUTCH HUB CPL.OUTER CLUTCH HUB CPL.
-
247032002000 INNER CLUTCH HUBINNER CLUTCH HUB
-
347032003000 PRESSURE CAPPRESSURE CAP
-
447032001100 OUT. CLUTCH HUB LOOSEOUT. CLUTCH HUB LOOSE
-
547032005000 CLUTCH SPRINGCLUTCH SPRING
-
647032006000 SPRING RETAIN. 5,1X10,2X15X2,5SPRING RETAIN. 5,1X10,2X15X2,5
-
70015050203 HH COLLAR SCREW M 5X20 WS=8HH COLLAR SCREW M 5X20 WS=8
-
847032008000 RIVET DIN0661 5X14RIVET DIN0661 5X14
-
1047032010000 STEEL DISCSTEEL DISC
-
1147032011000 LINING DISCLINING DISC
-
1547032015000 BUSHING 20X25X20,5BUSHING 20X25X20,5
-
160405252910 NEEDLE BEAR K 25X29X10NEEDLE BEAR K 25X29X10
-
1747032017000 SUPPORT WASHER 18,5X35X1,5 03SUPPORT WASHER 18,5X35X1,5 03
-
2047032020000 STOP DISC 20X32X2STOP DISC 20X32X2
-
2647032026000 DAMPING ELEMENTDAMPING ELEMENT
-
2847032028000 RETAINING PLATERETAINING PLATE
-
5447032054000 PRESSURE PLATEPRESSURE PLATE
-
5847032058000 PUSH RODPUSH ROD
-
6147132061044 OUTPUT CYLINDER CPL.OUTPUT CYLINDER CPL.
-
6247132066000 PISTON CPL.PISTON CPL.
-
6447132064000 BLEEDER SCREW WITH CAPBLEEDER SCREW WITH CAP
-
650770031018 O-RING 31,47X1,78O-RING 31,47X1,78
-
6847032068000 BALL D=6MMBALL D=6MM
-
700015060163 HH COLLAR SCREW M 6X16 WS=8HH COLLAR SCREW M 6X16 WS=8
-
710015060303 HH COLLAR SCREW M 6X30 SW=8HH COLLAR SCREW M 6X30 SW=8
-
9847032098000 AXIAL NEEDLE BEARINGAXIAL NEEDLE BEARING
-
9947032010010 CLUTCH KITCLUTCH KIT
