W A TER PUMP для Ktm 250 XCF - 2016 года выпуска
-
№АртикулНазвание
-
179235052000 WATER PUMP COVERWATER PUMP COVER
-
279235053000 GASKET F. WATER PUMP COVERGASKET F. WATER PUMP COVER
-
30025060456 HH COLLAR SCREW M6X45HH COLLAR SCREW M6X45
-
40025060256 HH COLLAR SCREW M6X25HH COLLAR SCREW M6X25
-
50603061001 CU-SEAL RING DIN7603-6X10X1CU-SEAL RING DIN7603-6X10X1
-
60402040980 NEEDLE ROL.DIN5402 NRB 4X9,8NEEDLE ROL.DIN5402 NRB 4X9,8
-
761230045000 CAP NUT M6 STAINLESS STEELCAP NUT M6 STAINLESS STEEL
-
879235055044 WATER PUMP WHEEL CPL.WATER PUMP WHEEL CPL.
-
1007601530451 SHAFT SEAL RING 15X30X4.5 BAUDSHAFT SEAL RING 15X30X4.5 BAUD
-
9979235055015 WATER PUMP REP .WATER PUMP REP .
Все узлы модели:
- ACCESSORIES KIT
- AIR FILTER
- BA TTER Y
- BALANCER SHAFT
- BRAKE CALIPER FRONT
- BRAKE CALIPER REAR
- CLUTCH
- CLUTCH COVER
- COOLING SYSTEM
- CRANKSHAFT PISTON
- CYLINDER
- CYLINDER HEAD
- DECAL
- ELECTRIC STARTER
- ENGINE CASE
- EXHAUST SYSTEM
- FRAME
- FRONT FORK DISASSEMBLED
- FRONT FORK TRIPLE CLAMP
- FRONT WHEEL
- FUEL PUMP
- HAND BRAKE CYLINDER
- HANDLEBAR CONTROLS
- IGNITION SYSTEM
- LUBRICATING SYSTEM
- MASK FENDERS
- PRO LEVER LINKING
- REAR BRAKE CONTROL
- REAR WHEEL
- SHIFTING MECHANISM
- SHOCK ABSORBER
- SHOCK ABSORBER DISASSEMBLED
- SIDE- / CENTER STAND
- SWING ARM
- TANK SEAT COVERS
- THROTTLE BODY
- TIMING DRIVE
- TRANSMISSION - COUNTERSHAFT
- TRANSMISSION - MAIN SHAFT
- V AL VE DRIVE
- • W A TER PUMP
- WIRING HARNESS
- WP SHIMS FOR SETTING
