CHOKE PLATE AND THROTTLE LEVERS для Mercury - XR-4 0B242885 THRU 0C100860
-
№АртикулНазвание
-
167245T BRACKET, COWL MOUNTING (UPPER)BRACKET, COWL MOUNTING (UPPER)
-
225-67272 GROMMET, COWL MOUNTING BRACKETGROMMET, COWL MOUNTING BRACKET
-
390435 MOUNT, COWL MOUNTING BRACKETMOUNT, COWL MOUNTING BRACKET
-
412-29245 WASHER, (.281 x .500 x .060) Stainless Steel, MOUNT ATTACHINGWASHER, (.281 x .500 x .060) Stainless Steel, MOUNT ATTACHING
-
511-35888 NUT, (.250-28) Stainless Steel, MOUNT ATTACHINGNUT, (.250-28) Stainless Steel, MOUNT ATTACHING
-
7799831 PLATE, CHOKEPLATE, CHOKE
-
827-672741 GASKET, CHOKE PLATE TO CARBURETORGASKET, CHOKE PLATE TO CARBURETOR
-
910-68000 SCREW, (.250-28 x 1.00), CHOKE PLATE TO CARBURETORSCREW, (.250-28 x 1.00), CHOKE PLATE TO CARBURETOR
-
1012-20583 WASHER, CHOKE PLATE SCREWWASHER, CHOKE PLATE SCREW
-
1127-672751 GASKET, COVERGASKET, COVER
-
1267246T COVER, INDUCTION SILENCERCOVER, INDUCTION SILENCER
-
1310-30720 SCREW, (.250-20 x 2.25), COVER TO CHOKE PLATESCREW, (.250-20 x 2.25), COVER TO CHOKE PLATE
-
1412-29245 WASHER, (.281 x .500 x .060) Stainless Steel, COVER SCREWWASHER, (.281 x .500 x .060) Stainless Steel, COVER SCREW
-
1513-26992 LOCKWASHER, (.250) Stainless Steel, COVER SCREWLOCKWASHER, (.250) Stainless Steel, COVER SCREW
-
1667760 LINK, ThrottleLINK, Throttle
-
1767759 LEVER, Throttle (UPPER)LEVER, Throttle (UPPER)
-
1841049 LEVER, Throttle (CENTER)LEVER, Throttle (CENTER)
-
1967749 LEVER, Throttle (LOWER)LEVER, Throttle (LOWER)
-
2010-15124 SCREW, (#10-32 x .750)SCREW, (#10-32 x .750)
-
2113-26996 LOCKWASHER, (#10) Stainless Steel, THROTTLE LEVER SCREWLOCKWASHER, (#10) Stainless Steel, THROTTLE LEVER SCREW
-
2212-56681 WASHER, (.203 x .500 x .032), THROTTLE LEVER SCREWWASHER, (.203 x .500 x .032), THROTTLE LEVER SCREW
-
2317-67297 PIN, Clevis, THROTTLE LEVERS TO THROTTLE LINKPIN, Clevis, THROTTLE LEVERS TO THROTTLE LINK
-
2412-89302 WASHER, (.203 x .406 x .040), CLEVIS PINWASHER, (.203 x .406 x .040), CLEVIS PIN
-
2518-26953 COTTER PIN, CLEVIS PINCOTTER PIN, CLEVIS PIN
-
2667748 ROLLER, LOWER THROTTLE LEVERROLLER, LOWER THROTTLE LEVER
-
2719-90585 PLUG, INDUCTION SILENCER COVERPLUG, INDUCTION SILENCER COVER
-
-27-11338A88 GASKET SET, Engine OverhaulGASKET SET, Engine Overhaul
