SUSPENSION - FRONT A - ARM W/ TIE RODS для Polaris XPEDITION 425 (A00CK42AA) (DESERT DUNE) - 2000 года выпуска
-
№АртикулНазвание
-
17542403 NUT, LOCKNUT, LOCK
-
25333367 BUSHINGBUSHING
-
31820567 TIE ROD, KIT(INCL. 4-9) (BUILT BEFORE8/16/99)TIE ROD, KIT(INCL. 4-9) (BUILT BEFORE8/16/99)
-
31820805 TIE, ROD ASSY. (INCL. 4-9) (BUILT AFTER 8/16/99)TIE, ROD ASSY. (INCL. 4-9) (BUILT AFTER 8/16/99)
-
45411291 SEAL, BOOT ROD END (1/2 IN)SEAL, BOOT ROD END (1/2 IN)
-
57061034 ROD END (RIGHT)ROD END (RIGHT)
-
67542711 NUT, JAMNUT, JAM
-
75020926 ROD, TIEROD, TIE
-
87547028 NUT, JAM (LEFT)NUT, JAM (LEFT)
-
97061033 ROD END, KIT (10MM/OUTER) (BUILT BEFORE 8/16/99)ROD END, KIT (10MM/OUTER) (BUILT BEFORE 8/16/99)
-
97061054 ROD, END 42 DEG (10MM, 1/2-20, LEFT) (BUILT AFTER 8/16/99)ROD, END 42 DEG (10MM, 1/2-20, LEFT) (BUILT AFTER 8/16/99)
-
105411920 BOOT, SEAL ROD END (10MM)BOOT, SEAL ROD END (10MM)
-
117517674 BOLT, HEXAGON WASH HEAD (BUILT AFTER 8/16/99)BOLT, HEXAGON WASH HEAD (BUILT AFTER 8/16/99)
-
127555806 WASHER (BUILT BEFORE 8/16/99)WASHER (BUILT BEFORE 8/16/99)
-
127556099 WASHER (BUILT AFTER 8/16/99)WASHER (BUILT AFTER 8/16/99)
-
137546904 NUT, CASTLENUT, CASTLE
-
147661203 PIN, COTTERPIN, COTTER
-
157080927 BALL, JOINT 52 DEGBALL, JOINT 52 DEG
-
165211121 BRACKET, BALL JOINTBRACKET, BALL JOINT
-
177512284 BOLT, SOCKETBOLT, SOCKET
-
185410548 BOOT, RUBBERBOOT, RUBBER
-
197542438 NUT, CASTLENUT, CASTLE
-
205431150 SHIELD, CV JOINT (LEFT/BLACK)SHIELD, CV JOINT (LEFT/BLACK)
-
205431149 SHIELD, CV JOINT (RIGHT/BLACK)SHIELD, CV JOINT (RIGHT/BLACK)
-
217512084 SCREWSCREW
-
225433066 BUSHING, A ARM LONGBUSHING, A ARM LONG
-
235020677 BUSHING, A-ARM SPACERBUSHING, A-ARM SPACER
-
245020681 SHAFT, A-ARMSHAFT, A-ARM
-
252200627 A-FRAME, KIT (LEFT)A-FRAME, KIT (LEFT)
-
252200628 A-FRAME, KIT (RIGHT)A-FRAME, KIT (RIGHT)
-
267080433 ZERK, FITTING THREADEDZERK, FITTING THREADED
-
287512492 SCREWSCREW
-
297552603 WASHERWASHER
-
307517527 BOLTBOLT
-
317515415 BOLTBOLT
