ELECTRICAL COMPONENTS для Polaris SCRAMBLER 90X (A02EA09CC) (YELLOW) - 2002 года выпуска
-
№АртикулНазвание
-
10450558 GAUGE,OIL LEVEL,ASSY.GAUGE,OIL LEVEL,ASSY.
-
20450549 SWITCH,MAIN,ASSY.SWITCH,MAIN,ASSY.
-
30450701 BOLT-HEX WASHERBOLT-HEX WASHER
-
40450554 RESISTOR,ASSY.RESISTOR,ASSY.
-
50450057 BOLT-PAN,PHILLIPSBOLT-PAN,PHILLIPS
-
60450553 RECTIFIER,REGULATORRECTIFIER,REGULATOR
-
70450557 LAMP,WARNING,OILLAMP,WARNING,OIL
-
80450309 BOLT-HEXBOLT-HEX
-
90450722 CDI BOX ASSY.CDI BOX ASSY.
-
100450563 BAG,TOOLBAG,TOOL
-
110450842 FUSE, 7.5 AMPFUSE, 7.5 AMP
-
120450555 RELAY,STARTER,ASSY.RELAY,STARTER,ASSY.
-
130450559 STRAPSTRAP
-
140450721 STRAPSTRAP
-
150450742 STRAPSTRAP
-
160450930 BATTERYBATTERY
-
170450921 ASSY.-MAIN WIREASSY.-MAIN WIRE
-
180450888 BOLT/NUT,BATTERYBOLT/NUT,BATTERY
-
190450556 BOLT-HEXBOLT-HEX
-
200450753 IGNITION COIL ASSY. (INCL. 22)IGNITION COIL ASSY. (INCL. 22)
-
210450890 WASHER-STARWASHER-STAR
-
220450889 CAP SPARK PLUGCAP SPARK PLUG
