ELECTRICAL COMPONENTS для Polaris PREDATOR 50 (A04KA05CA) - 2004 года выпуска
-
№АртикулНазвание
-
10451807 GUAGE OIL LEVEL ASSYGUAGE OIL LEVEL ASSY
-
20450549 SWITCH MAIN IGNITION WITH CLIPSWITCH MAIN IGNITION WITH CLIP
-
30451808 SWITCH MAIN ASSY (INCL. 2)SWITCH MAIN ASSY (INCL. 2)
-
40450701 BOLT HEXAGON WASHERBOLT HEXAGON WASHER
-
50450554 RESISTOR ASSYRESISTOR ASSY
-
60450057 BOLT PAN PHILLIPBOLT PAN PHILLIP
-
70450553 RECTIFIER REGULATORRECTIFIER REGULATOR
-
80451693 SWITCH SAFETYSWITCH SAFETY
-
90451146 LAMP OIL WARNINGLAMP OIL WARNING
-
100451020 SCREW PHILLIPSSCREW PHILLIPS
-
110451019 JUMPERJUMPER
-
120451021 CDI BOX ASSY (INCL. 10-11)CDI BOX ASSY (INCL. 10-11)
-
130450563 BAG TOOLBAG TOOL
-
140450842 FUSEFUSE
-
150450555 RELAY STARTER ASSYRELAY STARTER ASSY
-
160451043 BATTERY YUASA YOUTHBATTERY YUASA YOUTH
-
170450559 STRAPSTRAP
-
180451806 HARNESS MAIN WIRE ASSY (INCL 14)HARNESS MAIN WIRE ASSY (INCL 14)
-
190450888 BOLT NUT BATTERYBOLT NUT BATTERY
-
200451695 HORNHORN
-
210450701 BOLT HEXAGON WASHERBOLT HEXAGON WASHER
-
220450556 BOLT HEXAGONBOLT HEXAGON
-
230450753 IGNITION COIL ASSY (INCL. 25)IGNITION COIL ASSY (INCL. 25)
-
240450890 WASHER STARWASHER STAR
-
250450889 BASE, SPARK PLUG CAP (YOUTH ATV)BASE, SPARK PLUG CAP (YOUTH ATV)
Все узлы модели:
- AIR BOX ASSY.
- AXLE - REAR
- BRAKE - FRONT
- BRAKE - REAR
- BUMPER MOUNTING - FRONT
- CARBURETOR
- CHAIN / CHAIN GUARD
- CRANKCASE
- CRANKSHAFT W/ CYLINDER
- CYLINDER HEAD
- DECALS
- DRIVESHAFT - FRONT
- • ELECTRICAL COMPONENTS
- EXHAUST SYSTEM
- FENDER - REAR W/ SEAT
- FLY WHEEL COVER
- FRAME
- GENERATOR / STARTING MOTOR
- HANDLEBAR
- HEADLIGHT / BRAKELIGHT
- MOUNTING - ENGINE
- OIL PUMP
- OIL TANK / FUEL TANK
- PULLEY - DRIVE
- STARTER - RECOIL
- STEERING POST
- SUSPENSION
- SUSPENSION - SWING ARM W/ FOOTREST
- WHEEL - FRONT
- WHEEL - REAR
