SUSPENSION - FRONT A ARM W/ STRUT MOUNTING для Polaris MAGNUM 330 4X4 (A05CD32AB) (CAMO GREEN METALLIC) - 2005 года выпуска
-
№АртикулНазвание
-
17080927 BALL JOINT (52 DEG)BALL JOINT (52 DEG)
-
25211121 BRACKET BALL JOINTBRACKET BALL JOINT
-
35410548 BOOT RUBBERBOOT RUBBER
-
47512284 BOLT SOCKETBOLT SOCKET
-
57542438 NUT CASTLENUT CASTLE
-
67661203 PIN COTTERPIN COTTER
-
75435028-070 SHIELD CV BASIC (FRONT/LEFT/BLACK)SHIELD CV BASIC (FRONT/LEFT/BLACK)
-
75435029-070 SHIELD CV BASIC (FRONT/RIGHT/BLACK)SHIELD CV BASIC (FRONT/RIGHT/BLACK)
-
87512084 SCREWSCREW
-
97517909 BOLT HEXAGON WASH HEADBOLT HEXAGON WASH HEAD
-
107556099 WASHERWASHER
-
117547177 NUT HEXAGON LOCKNUT HEXAGON LOCK
-
125411920 BOOT SEAL ROD END (10MM)BOOT SEAL ROD END (10MM)
-
137061054 ROD END (10MM 1/2 20) (LEFT) (42 DEG)ROD END (10MM 1/2 20) (LEFT) (42 DEG)
-
147547028 NUT JAM (LEFT)NUT JAM (LEFT)
-
155020926 ROD TIEROD TIE
-
167542711 NUT JAMNUT JAM
-
177061034 ROD END (RIGHT)ROD END (RIGHT)
-
185411291 SEAL BOOT ROD END (1/2 IN)SEAL BOOT ROD END (1/2 IN)
-
197515415 SCREWSCREW
-
201820805 TIE ROD ASSY (INCL. 13 18)TIE ROD ASSY (INCL. 13 18)
-
215133806 SHAFT A ARMSHAFT A ARM
-
225434551 BUSHING A ARM LONG (BLACK)BUSHING A ARM LONG (BLACK)
-
232202280 A FRAME KIT (LEFT) (INCL. 6, 21, 22, 25, 26)A FRAME KIT (LEFT) (INCL. 6, 21, 22, 25, 26)
-
232202281 A FRAME KIT (RIGHT) (INCL. 6, 21, 22, 25, 26)A FRAME KIT (RIGHT) (INCL. 6, 21, 22, 25, 26)
-
257512492 SCREWSCREW
-
267552603 WASHER SPRING LOCKWASHER SPRING LOCK
-
277555832 WASHERWASHER
-
287542439 NUT, NYLOKNUT, NYLOK
