AIR INTAKE SYSTEM для Polaris OUTLAW 90 (A09KA9AD) (PINK) - 2009 года выпуска
-
№АртикулНазвание
-
10450824 BOLT-W/WSHR, HEXBOLT-W/WSHR, HEX
-
20453331 DUCT-INLET, CLUTCH COVERDUCT-INLET, CLUTCH COVER
-
30453655 CLAMPCLAMP
-
40453656 BOOT-DUCTBOOT-DUCT
-
50453187 CLIP-RETAININGCLIP-RETAINING
-
60450880 NUT-FLG W/SERRNUT-FLG W/SERR
-
70453184 SEPARATOR-OILSEPARATOR-OIL
-
80450865 FUEL LINE/CLIP ASMFUEL LINE/CLIP ASM
-
90454006 TUBE-OILTUBE-OIL
-
100453516 CLIP-OIL SEPARATORCLIP-OIL SEPARATOR
-
110454007 TUBE-OILTUBE-OIL
-
120450899 BOLT-HEXBOLT-HEX
-
130454008 TUBE-BREATHER, VENTILATEDTUBE-BREATHER, VENTILATED
-
140452795 CLIPCLIP
-
150453658 CLAMPCLAMP
-
160453659 BOOT-AIR CLEANERBOOT-AIR CLEANER
-
170453725 HOSE-DRAINHOSE-DRAIN
-
180453661 CLIPCLIP
-
190453518 BOLTBOLT
-
200453666 BRKT-MOUNT, AIR BOXBRKT-MOUNT, AIR BOX
-
210453660 CLIP-AIRBOX, OUTLAWCLIP-AIRBOX, OUTLAW
-
220453662 BOX-AIR CLEANERBOX-AIR CLEANER
-
230450340 BOLT-HEXBOLT-HEX
-
240453663 HOLDER-AIR FILTERHOLDER-AIR FILTER
-
250453664 FILTER-AIR BOX, OUTLAWFILTER-AIR BOX, OUTLAW
-
260453484 GASKET-COVER, AIRBOXGASKET-COVER, AIRBOX
-
270453665 COVER-AIR BOXCOVER-AIR BOX
-
280453332 DUCT-OUTLET, CLUTCH COVERDUCT-OUTLET, CLUTCH COVER
-
290453739 AIR BOX ASM. (INCL 15-27)AIR BOX ASM. (INCL 15-27)
