THROTTLE BODY для Polaris SPORTSMAN XP 850 (A09ZN85AQ) (NBU) - 2009 года выпуска
-
№АртикулНазвание
-
11203698 ASM-IAFM,TWIN,DUAL PORT (INCL. 4-11)ASM-IAFM,TWIN,DUAL PORT (INCL. 4-11)
-
21203737 ASM-PLENUM,AIR INTAKE (INCL 7)ASM-PLENUM,AIR INTAKE (INCL 7)
-
31203943 ASM-THROTTLE BODY DB (INCL. 15-17)ASM-THROTTLE BODY DB (INCL. 15-17)
-
41203568 INJECTOR-180G/MIN SINGLE CONEINJECTOR-180G/MIN SINGLE CONE
-
52520563 ASM-FUEL RAIL DUAL PNT 2.7BARASM-FUEL RAIL DUAL PNT 2.7BAR
-
65413283 SEAL-INTAKE PORTSEAL-INTAKE PORT
-
75413386 SEAL-INTAKE THROTTLE BODYSEAL-INTAKE THROTTLE BODY
-
85437322 INTAKE-MANIFOLD DUAL PORTINTAKE-MANIFOLD DUAL PORT
-
97518539 CONNECTORCONNECTOR
-
107518541 SCR-FUELRAIL,DUALPNT,M6X20SHCSSCR-FUELRAIL,DUALPNT,M6X20SHCS
-
117518844 SCR-M6X25MM,SHCSSCR-M6X25MM,SHCS
-
127519019 SCR-M6X1.065MM,BTNHTXCSSCR-M6X1.065MM,BTNHTXCS
-
137080474 CLAMP, HOSECLAMP, HOSE
-
143130543 GUIDE,CABLEGUIDE,CABLE
-
155413599 O-RING THROTTLE CAM COVERO-RING THROTTLE CAM COVER
-
165252518 COVER-THROTTLE CAMCOVER-THROTTLE CAM
-
173130924 SCREWSCREW
-
188450116-10 HOSEHOSE
-
198450114-20 HOSEHOSE
-
208450114-27 HOSEHOSE
-
217080003 CLAMP,HOSECLAMP,HOSE
