CARBURETOR для Polaris SPORTSMAN 90 [A16YAF09AA] - 2016 года выпуска
-
№АртикулНазвание
-
10454886 ASM., CARBURETOR [INCL. ALL]ASM., CARBURETOR [INCL. ALL]
-
20454190 ASM., CAPASM., CAP
-
30454191 SPRINGSPRING
-
40454192 CLIP, NEEDLECLIP, NEEDLE
-
50454193 ASM., JET NEEDLE [INCL. 26]ASM., JET NEEDLE [INCL. 26]
-
60454194 THROTTLE, VALVETHROTTLE, VALVE
-
70454887 JET, PILOTJET, PILOT
-
80454888 JET, MAINJET, MAIN
-
90454197 PIN, FLOATPIN, FLOAT
-
100454198 FLOATFLOAT
-
110454199 VALVE, FLOATVALVE, FLOAT
-
120454200 SEAL, FLOATSEAL, FLOAT
-
130454201 BOWL, FLOATBOWL, FLOAT
-
140453629 SCREWSCREW
-
150452814 CLIPCLIP
-
160454202 HOSE, DRAINHOSE, DRAIN
-
170454206 VALVE, NEEDLEVALVE, NEEDLE
-
180453625 HOSEHOSE
-
190453623 CLAMP, HOSECLAMP, HOSE
-
200452541 SCREWSCREW
-
210454203 CLIP, SUPPORTCLIP, SUPPORT
-
220453626 O-RINGO-RING
-
230454204 ASM., SCREW, AIRASM., SCREW, AIR
-
240455196 SPACERSPACER
-
250454205 ASM., SCREW, IDLEASM., SCREW, IDLE
-
260454263 E-CLIP, NEEDLE JETE-CLIP, NEEDLE JET
