COOLING SYSTEM для Polaris Genesis 4-Pass - 2001 года выпуска
-
№АртикулНазвание
-
15812237 GASKETGASKET
-
25434149-133 FITTING, THRU HULL 90 DEGREEFITTING, THRU HULL 90 DEGREE
-
37080475 CLAMP, HOSECLAMP, HOSE
-
47080598 CABLE TIECABLE TIE
-
57080138 CABLE TIECABLE TIE
-
65411689 HOSEHOSE
-
77080476 CLAMP, HOSECLAMP, HOSE
-
85020668 FITTING, INLET WATERFITTING, INLET WATER
-
95811045 MANIFOLD, EXHAUST ASSY.MANIFOLD, EXHAUST ASSY.
-
107052251 FITTING, INJECTOR EXHAUSTFITTING, INJECTOR EXHAUST
-
117052105 FITTING, SCREEN EXHAUSTFITTING, SCREEN EXHAUST
-
125521287-117 CONDUIT, FLEXCONDUIT, FLEX
-
135411542 HOSE, BILGEHOSE, BILGE
-
147515149 SCREW, SHOULDERSCREW, SHOULDER
-
157555836 WASHERWASHER
-
167051527 PLUG, PIPEPLUG, PIPE
-
177051008 THERMOSTAT (143 F.)THERMOSTAT (143 F.)
-
185412014 GASKET, THERMOSTATGASKET, THERMOSTAT
-
197556174 WASHERWASHER
-
205631136 COVER, THERMOSTATCOVER, THERMOSTAT
-
217041310 SPRING, COMPRESSIONSPRING, COMPRESSION
-
225433823 VALVE, POP OFFVALVE, POP OFF
-
235410860 SEAL, O-RING/ THERMOSTAT/ FITTINGSEAL, O-RING/ THERMOSTAT/ FITTING
-
245412116 HOSE, WATER OUTHOSE, WATER OUT
