EXHAUST SYSTEM для Polaris Genesis 4-Pass - 2001 года выпуска
-
№АртикулНазвание
-
17052105 FITTING, SCREEN EXHAUSTFITTING, SCREEN EXHAUST
-
27052251 FITTING, INJECTOR EXHAUSTFITTING, INJECTOR EXHAUST
-
35020668 FITTING, WATER INLETFITTING, WATER INLET
-
45411887 HOSE, COVER EXHAUST PIPEHOSE, COVER EXHAUST PIPE
-
57080972 CLAMP, HOSE CONSTANT TORQUECLAMP, HOSE CONSTANT TORQUE
-
67080907 CLAMP, HOSECLAMP, HOSE
-
75410853 STRAP, RUBBERSTRAP, RUBBER
-
85224472 HOOK, 'D'HOOK, 'D'
-
97621479 RIVETRIVET
-
105240134 CLIP, STRAPCLIP, STRAP
-
115812236 PADPAD
-
125812030 FOAM, SUPPORT REVERSE (REAR)FOAM, SUPPORT REVERSE (REAR)
-
135433650 RESONATOR (RIGHT)RESONATOR (RIGHT)
-
145411844 HOSE, RESONATOR (LEFT/RIGHT)HOSE, RESONATOR (LEFT/RIGHT)
-
155433649 RESONATOR (LEFT)RESONATOR (LEFT)
-
167515116 SCREWSCREW
-
177555836 WASHERWASHER
-
187555838 WASHER, LOCKWASHER, LOCK
-
195810529 SEAL, EXHAUST FITTINGSEAL, EXHAUST FITTING
-
205132446 FITTING, EXHAUSTFITTING, EXHAUST
-
217080445 CLAMP, HOSECLAMP, HOSE
-
222202171 RESONATOR/ OUTLET KITRESONATOR/ OUTLET KIT
-
235412044 HOSE, SILENCER/ RESONATORHOSE, SILENCER/ RESONATOR
-
241261112-067 SILENCER, ANGLED OUTLET ASSY. (BLACK)SILENCER, ANGLED OUTLET ASSY. (BLACK)
-
257516911 SCREWSCREW
-
267552608 WASHER, LOCKWASHER, LOCK
-
277555841 WASHER, FLATWASHER, FLAT
-
281261110 WELD, EXHAUST PIPE (BLACK)WELD, EXHAUST PIPE (BLACK)
-
295411547 GROMMET, RUBBER MOLDGROMMET, RUBBER MOLD
-
305411784 HOSE, PIPE/ SILENCERHOSE, PIPE/ SILENCER
-
315521546 HOSEHOSE
-
325132567 TUBE, SPACERTUBE, SPACER
-
337517562 SCREWSCREW
-
345811045 GASKET, EXHAUST FLANGEGASKET, EXHAUST FLANGE
-
351261125 MANIFOLD ASSY. (BLACK)MANIFOLD ASSY. (BLACK)
