INTAKE GRATE W/ RIDE PLATE для Polaris Genesis i 4-Pass - 2001 года выпуска
-
№АртикулНазвание
-
17080483 CABLE, TIE (4 INCH)CABLE, TIE (4 INCH)
-
28450070-235 PITOTPITOT
-
37547003 NUTNUT
-
47555873 WASHER, FLAT NYLONWASHER, FLAT NYLON
-
55810879 GASKET, PITOTGASKET, PITOT
-
65431634 FITTING, PILOT MOLDEDFITTING, PILOT MOLDED
-
75433011 SCOOP, INLETSCOOP, INLET
-
85132471 INSERTINSERT
-
95631130 PLATE, RIDE (BLACK)PLATE, RIDE (BLACK)
-
107517707 SCREWSCREW
-
115630886 GRATE, INLETGRATE, INLET
Все узлы модели:
- AIR INTAKE SYSTEM
- BATTERY BOX
- BILGE PUMP
- BILGE SIPHON
- COOLING SYSTEM
- CRANKCASE
- CRANKSHAFT W/ PISTONS
- DECALS
- DRIVE SHAFT W/ COUPLER
- ELECTRICAL BOX
- ELECTRONIC MODULE
- ENGINE MOUNTING W/ SHORT BLOCK
- EXHAUST SYSTEM
- FUEL SYSTEM
- FUEL TANK
- HANDLEBAR ASSY. W/ STEERING COLUMN
- HULL
- HULL
- • INTAKE GRATE W/ RIDE PLATE
- MANIFOLD- CYLINDER W/ IGNITION
- OIL PUMP
- OIL TANK
- PROPULSION
- REVERSE
- SEAT
- SHROUD W/ INSTRUMENTS AND MIRRORS
- STARTING MOTOR
- STEERING CABLE ASSY.
- STORAGE COMPARTMENT - FRONT
- THROTTLE BODY ASSY.
- TOOL KIT
