SEAT для Polaris Genesis i 4-Pass - 2001 года выпуска
-
№АртикулНазвание
-
12682566-070 STRAP ASSY., W/ CLIPS (BLACK)STRAP ASSY., W/ CLIPS (BLACK)
-
22682686-320 COVER SEAT (FRONT/ SILVER)COVER SEAT (FRONT/ SILVER)
-
39810357 STAPLE (OPT)STAPLE (OPT)
-
45433113-320 SHIELD SEAT (FRONT/ RIGHT)SHIELD SEAT (FRONT/ RIGHT)
-
55521520 TRIM, SEAT (FRONT)TRIM, SEAT (FRONT)
-
65521483 SEAL SEAT (FRONT)SEAL SEAT (FRONT)
-
77517732 SCREWSCREW
-
85521533 BUMPER, SEATBUMPER, SEAT
-
95433112-320 SHIELD SEAT (FRONT/ LEFT)SHIELD SEAT (FRONT/ LEFT)
-
105521490 BUMPERBUMPER
-
117516806 BOLTBOLT
-
127555838 WASHER, LOCKWASHER, LOCK
-
137555839 WASHER, FLATWASHER, FLAT
-
145431357 PLATE, LATCH SEAT BASE (BOTTOM)PLATE, LATCH SEAT BASE (BOTTOM)
-
155211314 PLATE, SEATBASE LATCHPLATE, SEATBASE LATCH
-
167042036 SPRING, SEATBASE LATCHSPRING, SEATBASE LATCH
-
175431358 HANDLE, SEAT BASE LATCHHANDLE, SEAT BASE LATCH
-
185431359 PLATE, SEATBASE LATCH (TOP)PLATE, SEATBASE LATCH (TOP)
-
192682761-320 SEAT ASSY. (FRONT/ SILVER) (INCL. 2-18)SEAT ASSY. (FRONT/ SILVER) (INCL. 2-18)
-
205521522 TRIM, SEAT (REAR)TRIM, SEAT (REAR)
-
215521484 SEAL, SEAT (REAR)SEAL, SEAT (REAR)
-
225433115-070 SHIELD SEAT (REAR/ RIGHT/ BLACK)SHIELD SEAT (REAR/ RIGHT/ BLACK)
-
235433376-070 CAP SEAT, END BASIC (BLACK)CAP SEAT, END BASIC (BLACK)
-
245432966 CLIP, XMAS TREECLIP, XMAS TREE
-
252682427-303 COVER SEAT (REAR/ BLACK)COVER SEAT (REAR/ BLACK)
-
267078541-133 DECAL, ''POLARIS'' SEATDECAL, ''POLARIS'' SEAT
-
262200891 DECAL APPLICATION KIT, VINYL''(FOR SEAT DECALS)DECAL APPLICATION KIT, VINYL''(FOR SEAT DECALS)
-
272682762-303 SEAT ASSY. (REAR/ BLACK) (INCL. 7, 8, 11-18, 20-26, 28)SEAT ASSY. (REAR/ BLACK) (INCL. 7, 8, 11-18, 20-26, 28)
-
285433114-070 SHIELD SEAT (REAR/ LEFT/ BLACK)SHIELD SEAT (REAR/ LEFT/ BLACK)
