COOLING SYSTEM для Polaris SLH 2-Pass Euro - 2001 года выпуска
-
№АртикулНазвание
-
17080475 CLAMP, HOSECLAMP, HOSE
-
25431444-133 FITTING, THRU HULL (WHITE)FITTING, THRU HULL (WHITE)
-
35811317 GASKETGASKET
-
45521287-45 CONDUIT, FLEX (1.250 ID)CONDUIT, FLEX (1.250 ID)
-
55411049 HOSE, PUMP OUTLETHOSE, PUMP OUTLET
-
65431784 FITTING, TEEFITTING, TEE
-
77080476 CLAMP, HOSECLAMP, HOSE
-
87052128 FITTING, SCREENFITTING, SCREEN
-
98450054-100 HOSE, WATERHOSE, WATER
-
105020747 FITTING, INJECTORFITTING, INJECTOR
-
115020668 FITTING, WATER INLETFITTING, WATER INLET
-
125411050 HOSE, INLETHOSE, INLET
-
137080138 CABLE, TIECABLE, TIE
-
147516727 BOLTBOLT
-
157516725 BOLTBOLT
-
161260694 MANIFOLD, EXHAUST ASSY. (BLACK)MANIFOLD, EXHAUST ASSY. (BLACK)
-
177555856 WASHER, FLATWASHER, FLAT
-
187552611 WASHER, LOCKWASHER, LOCK
-
197517004 BOLTBOLT
-
205811045 GASKET, EXHAUST FLANGEGASKET, EXHAUST FLANGE
-
215020746 FITTING, DRAINFITTING, DRAIN
-
225521398-13 CONDUIT, FLEX (.75''ID)CONDUIT, FLEX (.75''ID)
-
235432799 VALVE, POP OFFVALVE, POP OFF
-
247051008 THERMOSTAT (143 F.)THERMOSTAT (143 F.)
-
255412014 GASKET, THERMOSTAT (60D)GASKET, THERMOSTAT (60D)
-
267556174 WASHERWASHER
-
275631136 COVER, THERMOSTATCOVER, THERMOSTAT
-
287041310 SPRING, COMPRESSIONSPRING, COMPRESSION
-
295410860 SEAL, O-RING/THERMO/FITTINGSEAL, O-RING/THERMO/FITTING
-
305411479 HOSE, WATER OUT (3/4 ID.)HOSE, WATER OUT (3/4 ID.)
