OIL TANK для Polaris SLH 2-Pass Euro - 2001 года выпуска
-
№АртикулНазвание
-
15432843 CAP, OIL TANKCAP, OIL TANK
-
27080442 COUPLING, ENDCOUPLING, END
-
37080710 CHAIN, BEADCHAIN, BEAD
-
47621229 RIVETRIVET
-
55433914 INLET, OIL (.150)INLET, OIL (.150)
-
65811554 GASKET, OIL INLETGASKET, OIL INLET
-
77080772 CLAMP, HOSECLAMP, HOSE
-
87052130 ELBOW (90 DEG.)ELBOW (90 DEG.)
-
97080476 CLAMP, HOSECLAMP, HOSE
-
108450003-1525 FUEL LINE (1/4 ID 1525 CM.) (OPT)FUEL LINE (1/4 ID 1525 CM.) (OPT)
-
117052118 VALVE, VACUUM CHECKVALVE, VACUUM CHECK
-
125211866 PLATE, TANK OILPLATE, TANK OIL
-
137555961 WASHER, LOCKWASHER, LOCK
-
147555836 WASHERWASHER
-
157515143 SCREWSCREW
-
167080307 CLAMP, HOSECLAMP, HOSE
-
172530015 FILTER, OILFILTER, OIL
-
187080474 CLAMP, HOSECLAMP, HOSE
-
198450059-61 FUEL LINE (OPT)FUEL LINE (OPT)
-
207080483 CABLE TIE (4 IN.)CABLE TIE (4 IN.)
-
215432768 TANK, OILTANK, OIL
-
222410079 SENDER ASSY., OIL LEVELSENDER ASSY., OIL LEVEL
-
235433636 HOSE, FILL OILHOSE, FILL OIL
-
247661042 RIVET, POPRIVET, POP
-
257517241 SCREWSCREW
