ENGINE AIR INTAKE AND HULL AIR INLET для Polaris FREEDOM (IA) - 2004 года выпуска
-
№АртикулНазвание
-
15432138-070 PLUG, INTAKE SILENCER, BLACKPLUG, INTAKE SILENCER, BLACK
-
25410589 O RINGO RING
-
35133129 STUD-318, M6X2.691 W/STOPSTUD-318, M6X2.691 W/STOP
-
45830062 GASKET, CARB., UPPERGASKET, CARB., UPPER
-
55631118 BASE-INTAKEBASE-INTAKE
-
67517799 SCR, M6X1.0X130MMSCR, M6X1.0X130MM
-
72520185 FILTER, INTAKEFILTER, INTAKE
-
87170225 DECAL-POLARIS MARINE 700DECAL-POLARIS MARINE 700
-
95434114-070 COVER-INTAKE, W/BLACKCOVER-INTAKE, W/BLACK
-
107546708 NUTNUT
-
117661042 RIVET-POPRIVET-POP
-
125433220 FLANGEFLANGE
-
135411545 GASKETGASKET
-
147080439 CLAMP, HOSECLAMP, HOSE
-
155433082 DUCT, INLET, AIRDUCT, INLET, AIR
-
167080492 CABLE TIE, 11 INCHCABLE TIE, 11 INCH
Все узлы модели:
- BATTERY
- BILGE PUMP
- CARBURETOR
- COOLING SYSTEM
- CRANKCASE
- CRANKSHAFT AND PISTON
- CYLINDER AND MANIFOLD
- DECALS
- DRIVE SYSTEM
- ELECTRICAL BOX
- ELECTRICAL BOX MOUNTING
- • ENGINE AIR INTAKE AND HULL AIR INLET
- ENGINE FOGGING SYSTEM
- ENGINE MOUNTING W/ SHORT BLOCK
- EXHAUST SYSTEM
- FUEL SYSTEM
- FUEL TANK
- FUEL/WATER SEPARATOR
- HANDLEBAR W/ COVER
- HULL AND BODY
- INTAKE GRATE W/ RIDE PLATE
- MAGNETO
- OIL PUMP
- OIL TANK
- PROPULSION
- SEAT
- SHROUD
- STARTING MOTOR
- STEERING CABLE ASSY.
- STORAGE COMPARTMENT - FRONT
- TOOL KIT
