CRANKSHAFT W/ PISTON для Polaris MSX 140 (CA) - 2004 года выпуска
-
№АртикулНазвание
-
13021179 CIRCLIP, PISTON, 22MMX1.6 (2)CIRCLIP, PISTON, 22MMX1.6 (2)
-
32201631 KIT, PISTON, RING, STANDARD, 85MMKIT, PISTON, RING, STANDARD, 85MM
-
42202337 KIT-PISTON ASM 85MM STANDARD GR (INCL. 1-3)KIT-PISTON ASM 85MM STANDARD GR (INCL. 1-3)
-
52201445 CONNECTING, ROD, KITCONNECTING, ROD, KIT
-
63552112 BEARING, 17NDL, PSTNPIN. (IF BUILT BEFORE 10/15/03)BEARING, 17NDL, PSTNPIN. (IF BUILT BEFORE 10/15/03)
-
63514357 BEARING-17-22X27X25, PN PIN, KOYO (IF BUILT AFTER 10/15/03)BEARING-17-22X27X25, PN PIN, KOYO (IF BUILT AFTER 10/15/03)
-
77546909 NUTNUT
-
85432576 COUPLERCOUPLER
-
97555907 WASHERWASHER
-
103610044 SEALSEAL
-
117555905 BUSHINGBUSHING
-
123585503 BEARING, BALLBEARING, BALL
-
137721117 KEY, WOODRUFFKEY, WOODRUFF
-
145131744 CRANKSHAFT 3CRANKSHAFT 3
-
153514318 BEARING, BALLBEARING, BALL
-
165131745 CRANKSHAFT 2CRANKSHAFT 2
-
175131086 LABYRINTHLABYRINTH
-
185131746 CRANKSHAFT 1CRANKSHAFT 1
-
195412091 SEAL-FLANGE, 35X72X7, TRANSCOMSEAL-FLANGE, 35X72X7, TRANSCOM
-
205410613 O RINGO RING
-
215131195 COLLAR, CRANKSHAFTCOLLAR, CRANKSHAFT
-
-2202422 KIT-CRANKSHAFT 3 CYL HOKIT-CRANKSHAFT 3 CYL HO
Все узлы модели:
- AIR INTAKE SYSTEM
- BATTERY BOX
- COOLING SYSTEM
- CRANKCASE
- • CRANKSHAFT W/ PISTON
- DECALS
- DRIVE SHAFT W/ COUPLER
- ELECTRICAL BOX
- ENGINE MOUNTING W/ SHORT BLOCK
- ENHANCED STEERING PERFORMANCE
- EXHAUST SYSTEM
- FUEL TANK
- FUEL TANK
- HANDLEBAR W/ COVER
- HULL AND BODY
- HULL AND BODY
- IGNITION COILS
- INTAKE GRATE W/ RIDE PLATE
- MANIFOLD
- OIL PUMP
- OIL TANK
- PROPULSION
- REVERSE
- SEAT
- SHROUD AND STORAGE
- STARTING MOTOR
- STEERING CABLE
- STORAGE COMPARTMENT - FRONT
- THROTTLE BODY
- TOOL KIT
- WATER SIPHON
