INTAKE GRATE W/ RIDE PLATE для Polaris MSX 140 (CA) - 2004 года выпуска
-
№АртикулНазвание
-
17517897 SCR-M5X0.8X12, PH, PN, SSSCR-M5X0.8X12, PH, PN, SS
-
27556270 WASHER-LOCK, 5MM-SSWASHER-LOCK, 5MM-SS
-
37556271 WASHER-FLAT, M5 X 10 X1-SSWASHER-FLAT, M5 X 10 X1-SS
-
42410344 ASM-PADDLE, WHEELASM-PADDLE, WHEEL
-
54010051-10 CONDUIT-CONVOLUTED, 100 CMCONDUIT-CONVOLUTED, 100 CM
-
67080138 CABLE TIECABLE TIE
-
75631257-329 PLATE-RIDE, BLACK (IF BUILT BEFORE 10/20/03)PLATE-RIDE, BLACK (IF BUILT BEFORE 10/20/03)
-
75631598-329 PLATE-RIDE, BLACK (IF BUILT AFTER 10/20/03)PLATE-RIDE, BLACK (IF BUILT AFTER 10/20/03)
-
85631330 SCOOP-INLETSCOOP-INLET
-
95631328-067 GRATE-INLET, MACH, BLACK (IF BUILT BEFORE 10/21/03GRATE-INLET, MACH, BLACK (IF BUILT BEFORE 10/21/03
-
95631605-067 GRATE-INLET, BLACK (IF BUILT AFTER 10/21/03)GRATE-INLET, BLACK (IF BUILT AFTER 10/21/03)
-
107518119 BOLT-M8X1.25X30-HX/FL-SSBOLT-M8X1.25X30-HX/FL-SS
Все узлы модели:
- AIR INTAKE SYSTEM
- BATTERY BOX
- COOLING SYSTEM
- CRANKCASE
- CRANKSHAFT W/ PISTON
- DECALS
- DRIVE SHAFT W/ COUPLER
- ELECTRICAL BOX
- ENGINE MOUNTING W/ SHORT BLOCK
- ENHANCED STEERING PERFORMANCE
- EXHAUST SYSTEM
- FUEL TANK
- FUEL TANK
- HANDLEBAR W/ COVER
- HULL AND BODY
- HULL AND BODY
- IGNITION COILS
- • INTAKE GRATE W/ RIDE PLATE
- MANIFOLD
- OIL PUMP
- OIL TANK
- PROPULSION
- REVERSE
- SEAT
- SHROUD AND STORAGE
- STARTING MOTOR
- STEERING CABLE
- STORAGE COMPARTMENT - FRONT
- THROTTLE BODY
- TOOL KIT
- WATER SIPHON
