CONSOLE для Polaris 500 RMK (S00SR5AS) - 2000 года выпуска
-
№АртикулНазвание
-
17512031 BOLTBOLT
-
25211573 SPACER, REGULATORSPACER, REGULATOR
-
34060123 REGULATOR (14.3VAC)REGULATOR (14.3VAC)
-
47541925 NUTNUT
-
57077367 DECAL, CONSOLE, IGNITIONDECAL, CONSOLE, IGNITION
-
67080138 STRAP PANDUITSTRAP PANDUIT
-
74010192 SOCKET, PACKARD #12047767SOCKET, PACKARD #12047767
-
84020063 HOUSINGHOUSING
-
94020092 TERMINAL, RINGTERMINAL, RING
-
104020057 HOUSING W/RECEPTACLEHOUSING W/RECEPTACLE
-
112460733 HARNESS, MAIN, GEN 2 COMMONHARNESS, MAIN, GEN 2 COMMON
-
127515199 SCREWSCREW
-
132200358 IGNITION SWITCH, KITIGNITION SWITCH, KIT
-
147555932 WASHER, NYLONWASHER, NYLON
-
157080734 CABLE, CHOKE, SINGLE, PULL (INCL. 16, 19)CABLE, CHOKE, SINGLE, PULL (INCL. 16, 19)
-
162200188 CHOKE CONTROL, KTICHOKE CONTROL, KTI
-
177621330 RIVET, POPRIVET, POP
-
185243049 GUIDE, RECOILGUIDE, RECOIL
-
197080229 NUTNUT
-
205410611 KEY, IGNITION W/CAP (SEE FOOTNOTE)KEY, IGNITION W/CAP (SEE FOOTNOTE)
-
217547035 NUT, IGNITIONNUT, IGNITION
-
225432906 CONSOLE, HYBRID (BLACK)CONSOLE, HYBRID (BLACK)
Все узлы модели:
- AIR BOX
- BRAKE ASSEMBLY
- CARBURETOR - FUEL LINES- MOUNTINGS AND LINKAGE
- CARBURETOR ASSEMBLY
- CHAINCASE ASSEMBLY
- CLUTCH - DRIVE
- CLUTCH - DRIVEN
- • CONSOLE
- COOLING SYSTEM
- CRANKCASE ASSEMBLY
- CYLINDER ASSEMBLY
- DECALS
- DRIVE TRAIN ASSEMBLY W/ DRIVE BELT
- ELECTRICAL - MAGNETO ASSEMBLY W/ COIL
- ENGINE MOUNTING W/ SHORT BLOCK
- EXHAUST SYSTEM
- HANDLEBAR ASSEMBLY
- HOOD - FOAM/FOIL
- HOOD ASSEMBLY W/ HEADLIGHT
- HOOD ASSEMBLY W/ WINDSHIELD
- NOSEPAN ASSEMBLY #1
- NOSEPAN ASSEMBLY #2
- OIL TANK ASSEMBLY
- PISTON AND CRANKSHAFT
- RAIL ASSEMBLY W/ IDLER WHEELS
- SEAT W/ GAS TANK ASSEMBLY
- SKI ASSEMBLY
- STARTER - RECOIL ASSEMBLY
- STEERING ASSEMBLY
- SUSPENSION - FRONT
- SUSPENSION - FRONT TORQUE ARM ASSEMBLY
- SUSPENSION - RAIL MOUNTING
- SUSPENSION - REAR TORQUE ARM ASSEMBLY
- TOOL KIT
- TUNNEL ASSEMBLY
- WATER PUMP/OIL PUMP
