HOOD ASSEMBLY W/ HEADLIGHT для Polaris 700 SKS (S00SS7AS) - 2000 года выпуска
-
№АртикулНазвание
-
11011944-067 MOUNT, WELD, HEADLIGHTMOUNT, WELD, HEADLIGHT
-
27515107 BOLTBOLT
-
37670057 NUT, SPEEDNUT, SPEED
-
42433016 HEADLAMP, ASSY. THREE BULB (INCL. BULBS)HEADLAMP, ASSY. THREE BULB (INCL. BULBS)
-
54010253 BULB, HEADLIGHT, 50 WATTBULB, HEADLIGHT, 50 WATT
-
62870448 BULB, QUARTZ. HEADLIGHT, INDYBULB, QUARTZ. HEADLIGHT, INDY
-
75431855 LENS, CLEAR REFLECTOR (LEFT)LENS, CLEAR REFLECTOR (LEFT)
-
75431856 LENS, CLEAR REFLECTOR (RIGHT)LENS, CLEAR REFLECTOR (RIGHT)
-
85811907 SEAL, REFLECTOR, SRPSEAL, REFLECTOR, SRP
-
92632069-246 HOOD, SVC W/O SCREENS ASSY. (BLUE) (INCL. FOAM/FOIL)HOOD, SVC W/O SCREENS ASSY. (BLUE) (INCL. FOAM/FOIL)
-
107511953 SCREWSCREW
-
117670040 CLIP, U TYPECLIP, U TYPE
-
127517746 BOLT, TEE ADJUSTER, 2.25BOLT, TEE ADJUSTER, 2.25
-
137041308 SPRING, HEADLIGHT ADJUSTSPRING, HEADLIGHT ADJUST
-
145811886 FOAM, HEADLIGHT SEAL, W/PSA SRPFOAM, HEADLIGHT SEAL, W/PSA SRP
-
157080887 KNOB, HEADLIGHT, ADJUST, LOCKING BKNOB, HEADLIGHT, ADJUST, LOCKING B
-
161012750 HINGE (LEFT) (UPPER)HINGE (LEFT) (UPPER)
-
161012751 HINGE (RIGHT) (UPPER)HINGE (RIGHT) (UPPER)
-
175242948 PLATE, BOLTPLATE, BOLT
-
187515184 BOLTBOLT
-
197515203 BOLTBOLT
-
207542122 NUT, LOCKNUT, LOCK
-
215242678 PLATE, HINGE (LOWER)PLATE, HINGE (LOWER)
-
225242945 BRACE, HOOD (UPPER)BRACE, HOOD (UPPER)
-
235242946 BRACE, HOOD (LOWER)BRACE, HOOD (LOWER)
-
247661637 RIVET, INTERLOCK ZRIVET, INTERLOCK Z
-
257041732 SPRING, EXT.SPRING, EXT.
-
267041760 SPRING, ATTACHMENT RINGSPRING, ATTACHMENT RING
-
277080372 CLAMP, RETAINERCLAMP, RETAINER
-
287517441 SCREWSCREW
-
295432931 SCREEN, HYB (FRONT)SCREEN, HYB (FRONT)
