STEERING ASSEMBLY для Polaris 800 RMK 159 VERTICAL ESCAPE (S03NN8CS) - 2003 года выпуска
-
№АртикулНазвание
-
17061109 ROD END 3/8, 50Ш (RIGHT)ROD END 3/8, 50Ш (RIGHT)
-
27542401 NUT HEX (RIGHT)NUT HEX (RIGHT)
-
35334147 TIE RODTIE ROD
-
47542424 NUT (LEFT)NUT (LEFT)
-
57061075 ROD END 3/8 (LEFT) HI-ANGLE, PRROD END 3/8 (LEFT) HI-ANGLE, PR
-
67061076 ROD END 3/8 (RIGHT) HI-ANGLE, PRROD END 3/8 (RIGHT) HI-ANGLE, PR
-
75333772 ROD, STEERING RACK, 11.50ROD, STEERING RACK, 11.50
-
85333773-067 ROD, DRAGLINK, 12.50, STEELROD, DRAGLINK, 12.50, STEEL
-
97542439 NUT NYLOKNUT NYLOK
-
105132106 BUSHING REDUCER, 12MM TO .385BUSHING REDUCER, 12MM TO .385
-
111820957 PITMAN ARM ASSY. (INCL. 10, 12, 14)PITMAN ARM ASSY. (INCL. 10, 12, 14)
-
125133423 SPACER TUBE PITMAN/IDLER ARMSSPACER TUBE PITMAN/IDLER ARMS
-
137512435 SCREWSCREW
-
143514320 BEARING BALL, 600ILLUBEARING BALL, 600ILLU
-
151820959 IDLER ARM ASSY. (INCL. 10, 12, 14)IDLER ARM ASSY. (INCL. 10, 12, 14)
