AIR BOX для Polaris 400 IQ AND EURO (S07MX4CS/CE) - 2007 года выпуска
-
№АртикулНазвание
-
17512253 SCREWSCREW
-
27552604 WASHERWASHER
-
35436023 TUBE-INTAKETUBE-INTAKE
-
45813143 FOAM-TUBE/AIRBOXFOAM-TUBE/AIRBOX
-
57073426 DECAL, GREASINGDECAL, GREASING
-
65436090 STRAP-RUBBERSTRAP-RUBBER
-
81203434 ASM-AIRBOX SILENCER, 440 (INCL. 5)ASM-AIRBOX SILENCER, 440 (INCL. 5)
-
95413121 BOOT-CARB.TMX, 440BOOT-CARB.TMX, 440
-
105249079 BRKT-TUBE INTAKEBRKT-TUBE INTAKE
-
117515166 SCREWSCREW
-
127542153 NUT, NYLOK, FLANGEDNUT, NYLOK, FLANGED
Все узлы модели:
- • AIR BOX
- BRAKE ASSEMBLY
- CARBURETOR ASSEMBLY
- CHAINCASE ASSEMBLY
- CHASSIS ASSEMBLY W/FOOTRESTS
- CLUTCH - DRIVE
- CLUTCH - DRIVEN
- CONSOLE
- COOLING SYSTEM
- CRANKCASE ASSEMBLY
- CYLINDER ASSEMBLY
- DECALS
- DRIVE TRAIN ASSEMBLY W/ DRIVE BELT
- ELECTRICAL - MAGNETO ASSEMBLY W/ COIL
- ELECTRICAL COMPONENTS MOUNTING
- ENGINE MOUNTING W/ SHORT BLOCK
- EXHAUST SYSTEM
- FRAME - CHASSIS
- FUEL SYSTEM
- HANDLEBAR ASSEMBLY
- HARNESS W/ ACCESSORIES
- HOOD ASSEMBLY W/ WINDSHIELD
- HOOD MOUNTING W/ FRONT BUMPER
- NOSEPAN AND SIDEPANELS
- PISTON AND CRANKSHAFT
- SEAT W/ TAILLIGHT
- SKI ASSEMBLY
- STARTER - RECOIL ASSEMBLY
- STEERING ASSEMBLY
- STEERING POST - HOOP
- SUSPENSION - FRONT
- SUSPENSION - FRONT TORQUE ARM ASSEMBLY
- SUSPENSION - RAIL MOUNTING
- SUSPENSION - REAR
- SUSPENSION - REAR TORQUE ARM ASSEMBLY
- SUSPENSION - WALKER EVANS - FRONT TRACK SHOCK
- SUSPENSION - WALKER EVANS - REAR TRACK SHOCK
- SUSPENSION - WALKER EVANS - SHOCK IFS
- THROTTLE ASSEMBLY
- TOOL KIT
- WATER PUMP/OIL PUMP
